2.2

Technical specifications

Parameter
Printer
3D printing technology
Minimum dimensions for convenient
access (W × D × H)
Printer dimensions (W × D × H)
Printer weight
Build volume (W × D × H)
Layer thickness (Axis resolution)
XY resolution
Laser spot size (FWHM)
Resin cartridges
Resin dispensing system
Biocompatible materials
Supports
Operating environment
Operating temperature
Temperature control
Power requirements
Laser specifications
Radiation information
Connectivity
Wi-Fi connectivity
Ethernet connectivity
USB connectivity
Sound emission
Printer control
Alerts
Print preparation
File type
Unit
Form 3BL
Low Force Stereolithography (LFS)™
90 × 96 × 104 cm | 35.4 × 37.8 × 41 in
77 × 52 × 74 cm | 30.3 × 20.5 × 29.1 in
54.4 kg | 120 lb
33.5 × 20 × 30 cm | 13.2 × 7.9 × 11.8 in
25–300 microns | 0.001–0.012 in
25 microns | 0.001 in
85 microns | 0.0033 in
2
Automated
No
Auto-generated, Light-touch removal
18–28 °C | 64–82 °F
Low ambient humidity
Auto-heats to 35 °C | 95 °F
Air heated print chamber
100–240 VACMaximum 8.5 A
50/60 Hz
650 W
IEC 60825-1:2014 | EN 60825-1:2014
Class 1 laser product
2 Light Processing Units (LPUs)
In each Light Processing Unit (LPU):
405 nm violet laser | Maximum 250 mW
The Form 3BL is a Class 1 laser product. Accessible radiation
is within Class 1 limits.
Wi-Fi: 2.4, 5 GHz
Ethernet: 1000 Mbit
USB: 2.0
Protocol: IEEE 802.11 b/g/n
Frequency: 2.4 GHz, 5 GHz
Supported security: WPA/WPA2
RJ-45 Ethernet (10BASE-T/100BASE-TX/1000BASE-T) LAN Port
Connect with a shielded Ethernet cable (not included):
minimum Cat5, or Cat5e or Cat6 for 1000BASE-T.
USB (rev 2.0) B port with a USB A-B cable
Does not exceed 70 dB(A).
Interactive touchscreen
Touchscreen alerts, SMS/email via Dashboard,Two LED status
indicators, Speaker for audio alerts
PreForm desktop software
STL or OBJ
