• Air compressor (must support 10 SCFM airflow at 90 psi, such as a 4 hp compressor)
• Air fittings to connect Fuse Blast to compressed air source:
3/8" NPT Female to 1/4" industrial quick-disconnect hose coupling
°
EPDM air hose, ⅜ NPT male
°
Other fittings as required for the compressor (filter, pressure regulator, etc.)
°
• Shielded Ethernet cable (minimum Cat5, or Cat5e or Cat6 for 1000BASE-T)
4.2

Power and networking

For detailed guidance and visual assistance, visit support.formlabs.com.
Only use the supplied power cord or an alternative that meets the unit's power requirements.
Using an inadequately-rated power cable can damage your equipment or present a fire hazard.
The Fuse Blast requires an AC circuit that can provide at least 3 A at 230 VAC (EU)
or 6 A at 120 VAC (US), as well as reliable grounding. Power surges may disrupt
NOTICE
operation and/or permanently damage sensitive components, jeopardizing the
reliability of the product. Formlabs suggests the use of line conditioners or UPS in
regions with voltage fluctuations ≤ 10%.
Connect the air compressor system to a separate electrical circuit from the Fuse Blast.
Ensure that the machine maintains a constant connection to a secured network. Refer to
section 4.6 Setting up a network connection for more information.
4.3

Unboxing the machine

For detailed guidance and visual assistance, visit support.formlabs.com.
Prior to unboxing, ensure that the suitable workspace has been prepared according to section
4.1 Location and environs.
The Fuse Blast is a heavy object. A two person lift is required to prevent injury and
avoid damage to the machine.
CAUTION
4.3.1 Receiving
The standard Fuse Blast package ships on one pallet and contains the Fuse Blast media
blasting station, tumbler basket, transfer container, foot pedals, ESD wrist strap, 7 mm socket
wrench, 3 mm blast orifice, 4 mm blast orifice (installed), T20 Torx driver, and floor mat.
If you are in a building with palletized deliveries, ensure you have access to the loading dock.
Shipping dimensions
Shipping weight
Product weight
20
Fuse Blast
100 × 75 × 175 cm
39.4 × 29.8 × 69 in
194 kg
427.7 lb
164 kg
360 lb
Pallet including product and
boxes (if applicable)
117 × 91 × 194 cm
46 × 35.8 × 76.4 in
243 kg
535.7 lb
N/A
