Product Components - formlabs Fuse Blast Manual

Parameter
Product control
Included Accessories
Alerts
2.3

Product components

2.3.1 Fuse Blast – Front
Door latch: Secures the blasting chamber.
1
Blasting chamber door: A tempered glass
2
window prevents powder and debris from
leaving the Fuse Blast's workspace and
provides access to the tumbler basket and
blast gun.
Blast lights: Provides light to the Fuse
3
Blast's workspace.
Tumbler basket: Rotates to agitate parts and
4
ensure even coverage during automated
media blasting.
Blast gun: Blasts printed parts with media
5
and then cleans them with forced ionized air.
Blast arm: Holds blast gun in position for
6
assisted manual blasting or an automatic
blasting cycle.
Touchscreen: The LCD capacitive touch
7
user interface displays cleaning cycle information, settings, and error messages.
Blast gloves: Allows users to manipulate and clean items while the Fuse Blast chamber
8
doors are secured.
HEPA filter door: Sealed and interlocked door for accessing the HEPA air filter.
9
Media hopper window: Allows for visual check of powder level in the hopper.
10
Waste hopper window: Allows for visual check of waste level in the hopper.
1 1
Foot pedals: Manual controls for the air rinse and media blasting.
12
Media hopper valve: A knife valve used to close off and open the valve to empty the
13
media hopper.
Work surface: A grated surface in the interior of the blasting chamber that also allows media
14
and powder to drain into the chamber chute. Place parts here during manual blasting.
Grounding strap plug: A plug for attaching the included anti-static wrist strap used to protect
15
users and electronics from static electricity build up. Recommended for manual mode.
12
Unit
Interactive touchscreen, manual control pedals for manual
media blast and air rinse control
Transfer container
Control pedals
ESD wrist strap
7 mm socket wrench
3 mm blast orifice
4 mm blast orifice (installed)
T20 Torx driver
Floor mat
Touchscreen alerts
