2.2

Technical specifications

Parameter
Powder recovery station
3D printing technology
Minimum dimensions for convenient
access (W × D × H)
Powder recovery station dimensions
(W × D × H)
Powder recovery station weight
Build chamber dimensions (W × D × H)
Build chamber weight
Build volume (W × D × H)
Material refresh rate
Hopper capacity, fresh powder
Hopper capacity, used powder
Operating environment
Air handling
Power requirements
Vacuum requirements
Connectivity
Wi-Fi connectivity
Ethernet connectivity
USB connectivity
Sound emission
Powder recovery station control
Cartridge filling system
Alerts
Unit
Fuse Sift
Selective Laser Sintering (SLS)
221.1 × 122.0 × 218.0 cm | 87.1 × 48.0 × 85.8 in
99.1 × 61.0 × 157.0 cm (188.8 cm with hood open)
39.0 × 24.0 × 61.8 in (74.3 in with hood open)
93 kg | 205 lb (without build chamber or powder)
27.9 × 34.2 × 48.9 cm | 11.0 × 13.5 × 19.3 in
11 kg (17.6 kg, full with 20% packed powder)
24.3 lb (38.8 lb, full with 20% packed powder)
16.5 x 16.5 x 30.0 cm | 6.5 × 6.5 × 11.8 in (with radiused corners)
Print with up to 70% recycled powder
10.7 kg PA12 nylon | 23.6 lb PA12 nylon
9.8 kg PA12 nylon | 21.6 lb PA12 nylon
18–28 ºC | 68–81 ºF
Negatively pressurized hood with replaceable HEPA filter
With a vacuum that draws less than 6 A (230 VAC)/12 A (120
VAC):
EU: 230 VAC, 7.5 A (dedicated circuit)
US: 120 VAC, 15 A (dedicated circuit)
With a vacuum that draws more than 6 A (230 VAC)/12 A (120
VAC):
EU: 230 VAC, 10 A (dedicated circuit)
US: 120 VAC, 20 A (dedicated circuit)
Auxiliary vacuum that is grounded and bonded (e.g., a Class II,
Division 2 vacuum)
Wi-Fi: 2.4 GHz
Ethernet: 1000 Mbit
USB: 2.0
Protocol: IEEE 802.11 b/g/n
Frequency: 2.4 GHz
Supported security: WPA/WPA2
RJ-45 Ethernet (10BASE-T/100BASE-TX/1000BASE-T) LAN
port
Connect with a shielded Ethernet cable (not included):
minimum Cat5, or Cat5e or Cat6 for 1000BASE-T.
USB (rev 2.0) B port with a USB A-B cable
Does not exceed 84 dB(A).
Interactive touchscreen, physical buttons
Automated
Touchscreen alerts
Introduction | 11
