Table Of Contents - Salicru SLC X-TRA Series Technical Manual

Index
A) SRC RELAY CARD OPTION ............................................................ 9
1. CONTENTS OF PACKAGE ................................................................ 9
2. FUNCTION......................................................................................... 10
2.1 INSTALLATION ..............................................................................................10
UPS 100...800KVA 3PH-3PH ...........................................................................10
2.2
2.3 OPERATION ...................................................................................................11
B) THERMAL PROBE OPTION ........................................................... 12
1. FUNCTIONS ...................................................................................... 12
2. INSTALLATION................................................................................. 13
2.1 UPS EQUIPPED WITH THERMAL PROBE OPTION ....................................13
2.2 INSTALLATION OF THE OPTIONAL THERMAL PROBE KIT .....................15
C) REMOTE PANEL OPTION.............................................................. 16
1. CONTENTS OF PACKAGE .............................................................. 16
2. FUNCTION......................................................................................... 17
3. INSTALLATION................................................................................. 17
4. OPERATION...................................................................................... 19
D) REMOTE CONNECTION RS485 INTERFACE ............................... 20
1. CONTENTS OF PACKAGE .............................................................. 20
2. FUNCTION......................................................................................... 21
3. INSTALLATION................................................................................. 21
4. MOD-BUS DESCRIPTION ................................................................ 22
4.1 CABLE SPECIFICATION ...............................................................................23
4.2 CONFIGURATION DIP-SWITCHES OF MODBUS NETWORK.....................23
4.3 TERMINATING THE DATA NETWORK.........................................................23
4.4 BIASING THE DATA NETWORK...................................................................24
4.5 RS485 CONFIGURATION ..............................................................................24
4.6 CONNECTION TERMINAL BOARD...............................................................24
5. OPERATION...................................................................................... 25
E) GALVANIC INSULATION AND ADAPTATION TRASFORMER... 31
1. INTRODUCTION................................................................................ 31
2. GENERAL DESCRIPTION ................................................................ 31
6 of 69
100...800kVA UPS OPTIONS manual
JUD413767
2 / 32
First issue 10/01/11
