About the DCS Pro Back Plus

Focus Screen Overlay

The viewfinder's field of view is greater than that
of the imager. Therefore, an apparent focal
length magnification or telephoto effect appears
in the captured image.
Five viewfinder overlays are included with the
DCS Pro Back Plus. Each indicates the scene
content that is actually captured. Each overlay
has crop indicators which indicate the view
captured when you choose an Image Format
option (page 65).
Back
Contents

Applying an Overlay

1
2
3
Next Index
Remove the viewfinder from the camera body.
Lay a Focus Screen overlay over the focus
screen.
Replace the viewfinder.
19
