About the DCS Pro Back Plus
Overview
About the DCS Pro Back Plus
Rear
CANCEL
PWR
MENU
DCS Pro Back Plus
Image LCD Tilt Latch
Power button
Camera Ready LED
Back
Contents
Image LCD
Cancel button
Menu button
OK button
Four-way
OK
switch
Next
Front (Attaches to Camera Body)
* To obtain correct focus you must use either an
IR filter (included) or an anti-aliasing filter
(available as an accessory).
Index
Filter latch
IR Filter *
Slots for
connecting to
camera body
or MAMIYA
Interface Plate
16
