Messkreis
Messspannung U ..................................... profilabhängig, ±10 V, ±50 V
m
Messstrom I ............................................................................... ≤403 μA
m
Innenwiderstand R , Z ................................................................. ≥124 kΩ
i i
Zulässige Fremdgleichspannung U
Zulässige Netzableitkapazität C
..................................................................... profilabhängig, 0...1000 μF
Schaltglieder
Kontaktdaten nach IEC 60947-5-1
Gebrauchskategorie ......................AC-13 / AC-14 / DC-12 / DC-12 / DC-12
Bemessungsbetriebsspg ....................230 V / 230 V / 24 V / 110 V / 220 V
Bemessungsbetriebsstrom ............................5 A / 3A / 1 A / 0,2 A / 0,1 A
Bemessungsisolationsspannung ≤2000 m NN ................................250 V
Bemessungsisolationsspannung ≤3000 m NN .................................160 V
Minimale Kontaktbelastbarkeit .............................1 mA bei AC/DC ≥10 V
Sonstiges
EMV .................................................................................... IEC 61326-2-4
...................................................................................... DIN EN 50121-3-2
Schutzart Einbauten (DIN EN 60529) ..................................................IP40
Schutzart Klemmen (DIN EN 60529) .................................................. IP20
Das ISOMETER® isoRW685W-D(-B) wurde unter Beachtung folgender
Norm entwickelt: .............................................................DIN EN 61557-8
.............................................................................................DIN EN 50155
........................... DIN EN 45545-2:2016, Cert. 1436.GR.20210803.112252
EU-Konformitätserklärung
Der vollständige Text der EU-Konformitäts-
erklärung ist über den QR-Code verfügbar:
UKCA-Konformitätserklärung
Der vollständige Text der UKCA-Konformitäts-
erklärung ist über den QR-Code verfügbar:
Bender GmbH & Co. KG
Londorfer Straße 65
35305 Grünberg
Germany
Tel.: +49 6401 807-0
info@bender.de
www.bender.de
........................................... ≤1200 V
fg
................................................................
e
Alle Rechte vorbehalten.
Nachdruck und Vervielfältigung nur mit
Genehmigung des Herausgebers.
All rights reserved.
Reprinting and duplicating only with
permission of the publisher.
Measuring circuit
Measuring voltage U ........................... profile dependent, ±10 V, ±50 V
m
Measuring current I ...................................................................≤ 403 μA
m
Internal resistance R , Z ...............................................................≥ 124 kΩ
i i
Permissible extraneous DC voltage U
Permissible system leakage capacitance C
..................................................... dependent on the profile, 0...1000 μF
Switching elements
Contact data acc. to IEC 60947-5-1
Utilisation category .......................AC-13 / AC-14 / DC-12 / DC-12 / DC-12
Rated operational voltage ..................230 V / 230 V / 24 V / 110V / 220 V
Rated operational current ............................. 5 A / 3 A / 1 A / 0,2 A / 0,1 A
Rated insulation voltage ≤2000 m NN .............................................250 V
Rated insulation voltage ≤3000 m NN ............................................160 V
Minimum contact rating ..........................................1 mA at AC/DC ≥10 V
Other
EMC .................................................................................... IEC 61326-2-4
..................................................................................... DIN EN 50121-3-2
Degree of protection, built-in components (DIN EN 60529) ................IP40
Degree of protection, terminals (DIN EN 60529) .................................IP20
The ISOMETER® has been developed in compliance with the following
standards: .........................................................................DIN EN 61557-8
.............................................................................................DIN EN 50155
........................... DIN EN 45545-2:2016, Cert. 1436.GR.20210803.112252
EU Declaration of Conformity
The full text of the EU Declaration of Confor-
mity is available via the QR Code:
UKCA Declaration of Conformity
The full text of the UK Declaration of Conform-
ity is available via the QR Code:
© Bender GmbH & Co. KG, Germany
Subject to change! The specified
standards take into account the edition
valid until 03/2024 unless otherwise
indicated.
........................................≤ 1200 V
fg
................................................
e
