Eu-Konformitätserklärung; Eu Declaration Of Conformity - Bender ISOMETER isoHR1685DW-925 Quick Start Manual

Messkreis
Messspannung U (Spitzenwert) .....................................................±50 V
m
Innenwiderstand DC R ..................................................................≥ 70 kΩ
i
Zul. Fremdgleichspannung U
fg
Zulässige Netzableitkapazität C
profilabhängig .......................................................................0...2000 μF
Schnittstellen
Schnittstelle/Protokoll ...............................................................................
RS-485/BMS/Modbus RTU
Schaltglieder
Schaltglieder 3 Wechsler:
K1 .................................................................... (Isolationsfehler, Alarm 1)
K2 .................................................................... (Isolationsfehler, Alarm 2)
K3 ....................................................................................... (Gerätefehler)
Kontaktdaten nach IEC 60947-5-1
Bemessungsisolationsspannung ......................................................250 V
Minimale Kontaktbelastbarkeit ............................ 1 mA bei AC/DC ≥10 V
Sonstiges
EMV .................................................................................... IEC 61326-2-4
Schutzart Einbauten (DIN EN 60529) ..................................................IP30
Schutzart Klemmen (DIN EN 60529) ...................................................IP30
EU-Konformitätserklärung
Link zum vollständigen Text der EU-Konformi-
tätserklärung ist über den QR-Code verfügbar:
UKCA-Konformitätserklärung
Der vollständige Text der UKCA-Konformitäts-
erklärung ist über den QR-Code verfügbar:
Bender GmbH & Co. KG
Londorfer Straße 65
35305 Grünberg
Germany
Tel.: +49 6401 807-0
info@bender.de
www.bender.de
...............................................≤ DC 1600 V
................................................................
e
Alle Rechte vorbehalten.
Nachdruck und Vervielfältigung nur mit
Genehmigung des Herausgebers.
All rights reserved.
Reprinting and duplicating only with
permission of the publisher.
Measuring circuit
Measuring voltage U (peak).......................................................... ±50 V
m
Internal resistance DC R ................................................................≥ 70 kΩ
i
Permissible extr. DC voltage U
Permissible system leakage capacitance C
profile dependent ..................................................................0...2000 μF
Interfaces
Interface/protocol ......................................................................................
RS-485/BMS/Modbus RTU
Switching elements
Switching elements 3 changeover contacts:
K1 .....................................................................(insulation fault Alarm 1)
K2 .....................................................................(insulation fault Alarm 2)
K3 ........................................................................................ (device error)
Contact data acc. to IEC 60947-5-1
Rated insulation voltage ..................................................................250 V
Minimum contact rating ........................................ 1 mA at AC/DC ≥ 10 V
Other
EMC .................................................................................... IEC 61326-2-4
Degree of protection, built-in components (DIN EN 60529) .............. IP30
Degree of protection, terminals (DIN EN 60529) ............................... IP30
EU Declaration of Conformity
The full text of the EU Declaration of Conformity
is available via the QR Code:
UKCA Declaration of Conformity
The full text of the UK declaration of conformity
is available via the QR Code:
© Bender GmbH & Co. KG, Germany
Subject to change! The specified
standards take into account the edition
valid until 01/2024 unless otherwise
indicated.
.............................................≤ DC 1600 V
fg
................................................
e
