IARMOR EDGE™
BEFORE INSTALLATION
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS
ARE PRESENT. READ INSTRUCTIONS CAREFULLY
BEFORE STARTING INSTALLATION. ASSISTANCE IS
RECOMMENDED. THANK YOU FOR CHOOSING OUR
PRODUCT!
*DRILLING NOT REQUIRED
*TRIMMING NOT REQUIRED
Item
QTY
1#
3
Driver Front / Passenger Center & Rear Mounting Brackets
2#
3
Passenger Front / Driver Center & Rear Mounting Brackets
3#
12
M8X1.25-20mm Hex Bolts
M8 Large Flat Washers
4#
18
5#
12
M8 Lock Washers
3 #
iArmor
Description
4 #
5 #
Customer Support: info@iarmorauto.com
®
Fastener Size
Tightening Torque (ft-lbs)
6mm
8mm
10mm
12mm
14mm
Item
QTY
6#
12
M8 Hex Nuts
7#
44
M6X1-20mm T-Bolts
8#
44
M6 Large Flat Washers
9#
44
M6 Nylon Lock Nuts
6 #
7 #
1
PART#: IA-N022
Required
√
6-7
16-18
√
31-32
X
56-58
X
92-94
X
Description
9 #
8 #
Rev. 20220301
