Icom IC-905 Reference Manual page 5

REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
14* 08 00 00 ~ 02 55 Send/read [TWIN PBT] (PBT2)
09 00 00 ~ 02 55 Send/read CW pitch (5 Hz steps)
0A 00 00 ~ 02 55 Send/read the selected band's RF
0B 00 00 ~ 02 55 Send/read MIC gain
0C 00 00 ~ 02 55 Send/read keying speed
0D 00 00 ~ 02 55 Send/read Notch filter setting
0E 00 00 ~ 02 55 Send/read the COMP level
0F 00 00 ~ 02 55 Send/read the Break-IN Delay setting
12 00 00 ~ 02 55 Send/read NB level
15 00 00 ~ 02 55 Send/read Monitor audio [MONI] level
16 00 00 ~ 02 55 Send/read the VOX gain
17 00 00 ~ 02 55 Send/read the Anti VOX gain
19 00 00 ~ 02 55 Send/read LCD backlight brightness
15* 1 01 00/01
02 00 00 ~ 02 55 Read S-meter level
05 00/01
07 00/01
11 00 00 ~ 02 55 Read the Po meter level
12 00 00 ~ 02 55 Read SWR meter level
13 00 00 ~ 02 55 Read ALC meter level
14 00 00 ~ 02 55 Read COMP meter level
15* 8 00 00 ~ 02 55 Read Vd meter level
16 00 00 ~ 02 55 Read Id meter level
16* 02 00/01
Description
position
( 00 00=max� Counter Clockwise ~
01 28=center ~ 02 55=max� Clockwise)
( 00 00=300 Hz ~ 01 28=600 Hz ~
02 55=900 Hz)
power
(00 00=Minimum ~ 02 55=Maximum)
(00 00=Minimum ~ 02 55=Maximum)
(00 00=6 WPM ~ 02 55=48 WPM)
( 00 00=max� Counter Clockwise ~
01 28=center ~ 02 55=max� Clockwise)
(00 00=0 ~ 02 55=10)
(00 00=2�0d ~ 02 55=13�0d)
(00 00=0% ~ 02 55=100%)
(00 00=0% ~ 02 55=100%)
(00 00=0% ~ 02 55=100%)
(00 00=0% ~ 02 55=100%)
(00 00=0% ~ 02 55=100%)
Read noise or S-meter squelch status
(00=Close, 01=Open)
( 00 00=S0, 01 20=S9,
02 41=S9+60 dB)
Read various squelch (tone squelch,
and so on) status
(00=Close, 01=Open)
Read the OVF status
( 00=OVF indicator is OFF,
01=OVF indicator is ON)
( 00 00=0% ~ 01 43=50% ~
02 13=100%)
( 00 00=SWR1�0, 00 48=SWR1�5,
00 80=SWR2�0, 01 20=SWR3�0)
(00 00=Minimum ~ 01 20=Maximum)
( 00 00=0 dB ~ 01 30=15 dB ~
02 10=25�5 dB)
(00 00=0 V ~ 00 40=5 V ~ 02 41=30 V)
(00 00=0 A ~ 01 21=2 A ~ 02 41=4 A)
Send/read the Preamp
(00=OFF, 01=ON)
Cmd� Sub cmd�
16* 12 01 ~ 03
22 00/01
40 00/01
41 00/01
42 00/01
43 00/01
44 00/01
45 00/01
46 00/01
47 00 ~ 02
48 00/01
4A 00/01
4B 00/01
4F 00/01
50 00/01
56 00/01
57 00 ~ 02
58 00 ~ 02
5B 00 ~ 02
5C 00 ~ 02
5D 00 ~ 03,
06 ~ 09
4
Data Description
Send/read the AGC time constant
(01=FAST, 02=MID, 03=SLOW)
Send/read the Noise blanker
(00=OFF, 01=ON)
Send/read the Noise reduction
(00=OFF, 01=ON)
Send/read the Auto Notch function
(00=OFF, 01=ON)
Send/read the Repeater tone
(00=OFF, 01=ON)
Send/read the Tone squelch
(00=OFF, 01=ON)
Send/read the Speech compressor
(00=OFF, 01=ON)
Send/read the Monitor [MONI]
function
(00=OFF, 01=ON)
Send/read the VOX function
(00=OFF, 01=ON)
Send/read the BK-IN function
( 00=BK-IN OFF, 01=Semi BK-IN ON,
02=Full BK-IN ON)
Send/read the Manual Notch function
(00=OFF, 01=ON)
Send/read the AFC function
(00=OFF, 01=ON)
Send/read the DTCS function
(00=OFF, 01=ON)
Send/read the Twin peak filter
(00=OFF, 01=ON)
( Can be turned ON only when Mark
and Shift are set to 2125 Hz and
170 Hz, respectively)
Send/read the Dial Lock function
(00=OFF, 01=ON)
Send/read DSP IF filter type in the
operating band
(00=SHARP, 01=SOFT)
Send/read the Manual Notch width
(00=WIDE, 01=MID, 02=NAR)
Send/read SSB transmit bandwidth
(00=WIDE, 01=MID, 02=NAR)
( One of following values is applied,
depending on the "COMP" status
(ON or OFF):
WIDE (Command: 1A 05
MID (Command: 1A 05
NAR (Command: 1A 05
Send/read the DSQL (Digital Call
Sign squelch)/CSQL (Digital Code
squelch) setting
(DV mode only)
(00=OFF, 01=DSQL, 02=CSQL)
Send/read the GPS TX mode
(00=OFF, 01=D-PRS, 02=NMEA)
Send/read the Tone Squelch function
( 00=OFF, 01=TONE, 02=TSQL,
03=DTCS, 06=DTCS (T),
07=TONE (T)/DTCS (R),
08=DTCS (T)/TSQL (R),
09=TONE (T)/TSQL (R))
00 17),
00 18), or
00 19))
