Gps/D-Prs Data - Icom IC-905 Reference Manual

REMOTE CONTROL
Remote control (CI-V) information
D Command formats

• GPS/D-PRS data

Command: 20 03 01 00, 01 01, 01 02, 01 03,
02 00, 02 01, 02 02, 02 03
Data number and description
Data number
00 D-PRS — Position
01 D-PRS — Object
02 D-PRS — Item
03 D-PRS — Weather
Position
Command: 20 03 01 00, 02 00
1 ~ 9
10
0 0 X X X X X X X X
∙∙∙∙∙∙
Data number
17 ~ 22
X X X X X X
∙∙∙∙∙∙
29 ~ 31 32 ~ 38
X X X X X X
∙∙∙∙∙∙
1 ~ 9: Call sign/SSID
(9 ASCII characters (A ~ Z, 0 ~ 9, /, -, space))
Symbol (2 ASCII characters (00h ~ EFh))
10, 11:
12 ~ 16: Latitude (dd°mm�mmm format)
17 ~ 22: Longitude (ddd°mm�mmm format)
23 ~ 26: Altitude (0�1 meter steps)
Course (1 degree steps)
27, 28:
29 ~ 31: Speed (0�1 km/h steps)
32 ~ 38: Date (UTC: yyyymmddHHMMSS)
( y: Year, m: Month, d: Day,
H: Hour, M: Minute, S: Second)
39 ~ 42: See the table below�
39 Power 40 Height
Data (W) (m/ft)
00 0 3/10
01 1 6/20
02 4 12/40
03 9 24/80
04 16 49/160
05 25 98/320
06 36 195/640
07 49 390/1280
08 64 780/2560
09 81 1561/5120
L The item, that is not contained the received data, is filled
with "FF�"
L FF: No signal has been received since the power was
turned ON�
Description
12 ~ 16
11
X X X X
∙∙∙∙∙∙
23 ~ 26
27 28
X X X X X X
∙∙∙∙∙∙
39 40 41
X X X X X X X X X X
∙∙∙∙∙∙
41 Gain 42 Directivity
(dB) (deg)
0 Omni-direction
1 45° NE
2 90° E
3 135° SE
4 180° S
5 225° SW
6 270° W
7 315° NW
8 360° N
9 —
Object
Command: 20 03
1 ~ 9
0 1 X X
∙∙∙∙∙∙
Data number
17 ~ 22
X X
29 ~ 31
X X
∙∙∙∙∙∙
42
X X X X
1 ~ 9: Call sign/SSID
(9 ASCII characters (A ~ Z, 0 ~ 9, /, -, space))
Symbol (2 ASCII characters (00h ~ EFh))
10, 11:
42
12 ~ 16: Latitude (dd°mm�mmm format)
17 ~ 22: Longitude (ddd°mm�mmm format)
23 ~ 26: Altitude (0�1 meter steps)
Course (1 degree steps)
27, 28:
29 ~ 31: Speed (0�1 km/h steps)
32 ~ 38: Date (UTC: yyyymmddHHMMSS)
( y: Year, m: Month, d: Day,
H: Hour, M: Minute, S: Second)
39 ~ 42: See the table below�
39 Power
Data
00
01
02
03
04
05
06
07
08
09
43 ~ 51: Name
(9 ASCII characters (00h ~ EFh))
Type (01= Live, 00= Killed)
52:
L The item, that is not contained the received data, is filled
with "FF�"
L FF: No signal has been received since the power was
turned ON�
25
01 01, 02 01
12 ~ 16
10 11
X X X X X X X X
∙∙∙∙∙∙
23 ~ 26
X X X X X X
∙∙∙∙∙∙ ∙∙∙∙∙∙
32 ~ 38
X X X X X X X X X X X X
∙∙∙∙∙∙
43 ~ 51
52
∙∙∙∙∙∙ X X X X
40 Height 41 Gain 42 Directivity
(W) (m/ft) (dB)
0 3/10 0
1 6/20 1
4 12/40 2
9 24/80 3
16 49/160 4
25 98/320 5
36 195/640 6
49 390/1280 7
64 780/2560 8
81 1561/5120 9
X X
27
28
X X X X
39 40 41
(deg)
Omni-direction
45° NE
90° E
135° SE
180° S
225° SW
270° W
315° NW
360° N
—
