REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
1A* 06 See p� 23�
07 00/01
08* 00 ~ 02
1
09* 1 00/01
0A 00 ~ 02
0B 00/01
1B* 00 See p� 23�
01 See p� 23�
02 See p� 23�
07 See p� 23�
1C 00* 00/01
02* 00/01
03* 1 See p� 16�
1E 00* 1
01* 1 See p� 16�
02* 1
03* See p� 16�
1F* 00 See p� 23�
01 See p� 23�
02 See p� 23�
20 00 00* 00/01* 7
01 See p� 24�
02* See p� 24�
1
01 00* 00/01*
7
01 See p� 24�
02* 1 See p� 24�
02 00* 00/01* 7
01 See p� 24�
02* 1 See p� 24�
Description
Send/read the DATA mode setting
Send/read the NTP server access
(00=Terminate, 01=Initiate)
Read NTP server access result
(00= Accessing, or have not
accessed after Power ON,
01=Succeeded, 02=Failed)
Read the OVF indicator status
(00=OFF, 01=ON)
Send/read the Share Pictures
function status
( 00=OFF, 01=ON, 02=ON (Repeat))
L While transmitting the picture
using the DV Fast Data function,
sends ON even if the status is set
to OFF�
Send/read the RPT MONI setting
(00=OFF, 01=ON)
Send/read the Repeater tone frequency
Send/read the TSQL tone frequency
Send/read the DTCS code and polarity
Send/read the CSQL code (DV mode)
Send/read the transceiver's status
(00=RX, 01=TX)
Send/read the Transmit frequency
monitor (XFC)
(00=OFF, 01=ON)
Read the transmit frequency
Read number of available TX
frequency band
Read TX band edge frequencies
Read number of user-set TX
frequency band
Send/read the user-set TX band
edge frequencies
SET > My Station >
Send/read the My Call Sign setting
CS >
Send/read the UR, R1, R2 setting
SET > My Station >
Send/read the TX Message setting
Send/read the Auto DV RX Call
signs output
(00=OFF, 01=ON)
Output DV RX Call signs for
transceive
Read Auto DV RX Call signs
Send/read the Auto DV RX message
output
(00=OFF, 01=ON)
Output DV RX message for
transceive
Read Auto DV RX message
Send/read the Auto DV RX status
output
(00=OFF, 01=ON)
Output DV RX status for transceive
Read Auto DV RX status
Cmd� Sub cmd�
20 03 00* 00/01
01 00 See p� 25�
01 01 See p� 25�
01 02 See p� 26�
01 03 See p� 26�
02 00* 1 See p� 25�
02 01* See p� 25�
1
02 02* 1 See p� 26�
02 03* 1 See p� 26�
04 00* 00/01
01 See p� 26�
02* 1 See p� 26�
21* 00 See p� 27�
01 00/01
02 00/01
22 00 See p� 27�
01 00* 00/01
01 See p� 27�
02* 00/01
03* 00/01
04* 00/01
05* 00 ~ 10
23 00* 1 See p� 27�
01* 00/01
02* See p� 21�
24 00 00* 00/01
01 00/01
14
Data Description
Send/read the Auto DV RX
GPS/D-PRS data output
(00=OFF, 01=ON)
Output DV RX GPS/D-PRS Position
for transceive
Output DV RX D-PRS Object status
for transceive
Output DV RX D-PRS Item status
for transceive
Output DV RX D-PRS Weather
status for transceive
Read Auto DV RX GPS/D-PRS
Position status
Read Auto DV RX D-PRS Object
status
Read Auto DV RX D-PRS Item
status
Read Auto DV RX D-PRS Weather
status
Send/read Auto DV RX GPS/D-PRS
message output
(00=OFF, 01=ON)
Output DV RX D-PRS message for
transceive
Read Auto DV RX D-PRS message
status
Send/read the RIT frequency
Send/read the RIT setting
(00=OFF, 01=ON)
Send/read the ∂TX setting
(00=OFF, 01=ON)
Set the DV TX data (Up to 30 byte)
Set the Auto DV RX data output
(00=OFF, 01=ON)
Set the DV RX data for transceive
SET > DV/DD Set >
Send/read the DV Data TX setting
(00=PTT, 01=Auto)
SET > DV/DD Set > DV Fast Data
> Send/read the Fast Data setting
(00=OFF, 01=ON)
SET > DV/DD Set > DV Fast Data >
Send/read the GPS Data Speed setting
(00=Slow, 01=Fast)
SET > DV/DD Set > DV Fast Data >
Send/read the TX Delay (PTT) setting
( 00=OFF, 01=1sec ~ 10=10sec)
Read the position status
GPS > GPS Set >
Send/read the Position Input setting
(00=Internal GPS, 01=Manual)
GPS > GPS Set >
Send/read the Manual Position setting
Send/read TX output power setting
(00=OFF, 01=ON)
Set the TX output power for transceive
(00=OFF, 01=ON)
