Icom IC-905 Reference Manual page 14

REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
1A* 05 GPS > GPS TX Mode > D-PRS > TX Format > Weather
03 19 00 ~ 42
03 20 See p� 19�
03 21 00 ~ 02
GPS > GPS TX Mode > NMEA
03 22* 00/01
6
03 23* 00/01
6
03 24* 6 00/01
03 25* 6 00/01
03 26* 6 00/01
03 27* 6 00/01
03 28 See p� 19�
GPS > GPS Alarm
03 29 See p� 21�
03 30 00 ~ 02
GPS
03 31 00 ~ 06
DTMF > DTMF SET
03 32 00 ~ 03
VIDEO > VIDEO SET
03 33 00 00 ~ 02 55 Send/read the AV-IN Video Input
03 34 00 00 ~ 02 55 Send/read the AV-OUT Video Output
03 35 00 ~ 02
NB
03 36 00 00 ~ 02 55 Send/read the NB LEVEL setting
Description
Send/read the SSID setting
( 00= - - -, 01=(- 0),
02= -1 ~ 16= -15,
17= -A ~ 42= -Z)
Send/read the Comment setting
(Up to 43 characters)
Send/read the Time Stamp setting
(00=OFF, 01=DHM, 02=HMS)
GPS Sentence >
Send/read the RMC setting
(00=OFF, 01=ON)
GPS Sentence >
Send/read the GGA setting
(00=OFF, 01=ON)
GPS Sentence >
Send/read the GLL setting
(00=OFF, 01=ON)
GPS Sentence >
Send/read the GSA setting
(00=OFF, 01=ON)
GPS Sentence >
Send/read the VTG setting
(00=OFF, 01=ON)
GPS Sentence >
Send/read the GSV setting
(00=OFF, 01=ON)
Send/read the GPS Message setting
(Up to 20 characters)
Send/read the Alarm Area (Group)
setting
Send/read the Alarm Area (RX/
Memory) setting
( 00=Limited, 01=Extended,
02=Both)
Send/read the GPS Auto TX setting
( 00=OFF, 01=30sec, 02=1min,
03=3min, 04=5min, 05=10min,
06=30min)
Send/read the DTMF Speed setting
( 00=100ms, 01=200ms,
02=300ms, 03=500ms)
Level setting
(00 00=0% ~ 02 55=100%)
Level setting
(00 00=0% ~ 02 55=100%)
Send/read the View Mode setting
(00=Normal, 01=Full, 02=Zoom)
(00 00=0% ~ 02 55=100%)
Cmd� Sub cmd�
1A* 05 NB
03 37 00 ~ 09
03 38 00 00 ~ 02 55 Send/read the NB WIDTH setting
VOX
03 39 00 ~ 20
03 40 00 ~ 03
TX PWR LIMIT
03 41 00/01
03 42 00 00 ~ 02 55 Send/read the TX PWR LIMIT
03 43 00/01
03 44 00 00 ~ 02 55 Send/read the TX PWR LIMIT
03 45 00/01
03 46 00 00 ~ 02 55 Send/read the TX PWR LIMIT
03 47 00/01
03 48 00 00 ~ 02 55 Send/read the TX PWR LIMIT
03 49 00/01
03 50 00 00 ~ 02 55 Send/read the TX PWR LIMIT
03 51 00/01
03 52 00 00 ~ 02 55 Send/read the TX PWR LIMIT (10G)
CD
03 53 00/01
GPS Position
03 54 00 ~ 02
13
Data Description
Send/read the NB DEPTH setting
(00=1 ~ 09=10)
(00 00=1 ~ 02 55=100)
Send/read the VOX DELAY setting
( 00=0�0s ~ 20=2�0s in 0�1s steps)
Send/read the VOICE DELAY setting
( 00=OFF, 01=SHORT,
02=MID, 03=LONG)
Send/read the TX PWR LIMIT
(144M) function setting
(00=OFF, 01=ON)
(144M) setting
(00 00=0 ~ 02 55=100)
Send/read the TX PWR LIMIT
(430M) function setting
(00=OFF, 01=ON)
(430M) setting
(00 00=0 ~ 02 55=100)
Send/read the TX PWR LIMIT
(1200M) function setting
(00=OFF, 01=ON)
(1200M) setting
(00 00=0 ~ 02 55=100)
Send/read the TX PWR LIMIT
(2400M) function setting
(00=OFF, 01=ON)
(2400M) setting
(00 00=0 ~ 02 55=100)
Send/read the TX PWR LIMIT
(5600M) function setting
(00=OFF, 01=ON)
(5600M) setting
(00 00=0 ~ 02 55=100)
Send/read the TX PWR LIMIT (10G)
function setting
(00=OFF, 01=ON)
setting
(00 00=0 ~ 02 55=100)
Send/read the Call Sign Display/
Name Display setting
( 00=Call Sign Display,
01=Name Display)
Send/read the Compass Direction
setting
( 00=Heading Up, 01=North Up,
02=South Up)
