TECHNICAL SPECIFICATIONS

Maximum Fan and Radiator Compatibility:
- Motor: Electronically commuted spherical motor
- Rated voltage: 12V DC
- Power consumption: 18W
- Maximum pressure head: 5.3m
- Maximum flow: 1100L/h
- Maximum system temperature: 60°C
- Materials: NORYL GFN2, EPDM O-rings, Copper Coils, Stainless
Steel Shaft, Graphite Bushing
- Power connector: 4-Pin Molex and 4-Pin PWM FAN connector
Operational regime:
- PWM duty cycle: ~ 11-100%
- Default behavior: Runs at 100% duty cycle when no PWM feedback
signal is present

COMPATIBILITY

EK-VTX pumps can be used with all FLT reservoirs and REFLECTION
distribution plates compatible with DDC pumps, providing an
alternative option.
