- Page 1 EK-RES X3 D-RGB RESERVOIR USER GUIDE...
- Page 2 The following instructions are subject to change without notice. Please visit our website at www.ekwb.com for updates. Before you start using this product, please follow these basic guidelines: Carefully read the manual before beginning with the installation process.
-
Page 3: Table Of Contents
TABLE OF CONTENT BOX CONTENTS INSTALLING THE RESERVOIR MOUNTING HOLDERS RECOMMENDED RESERVOIR CONFIGURATION CONNECTING THE D-RGB LED STRIP TESTING THE LOOP SUPPORT AND SERVICE SOCIAL MEDIA - 3 -... -
Page 4: Box Contents
BOX CONTENTS Mounting holder EK-RES X3 150/ 250 D-RGB Reservoir Holder ( 2 pcs) Allen Key 2.5 mm ( 1pc) M4 nut ( 2 pcs) M4 Washer ( 2pcs) M4 Screw ( 2 pcs) Mounting mechanism Extender G1/4 - Nickel ( 2 pcs) EK-Plug G1/4 Acetal ( 4 pcs) Anti Vortex Foam (1 pc) - 4 -... -
Page 5: Installing The Reservoir Mounting Holders
INSTALLING THE RESERVOIR MOUNTING HOLDERS EK-RES X3 series reservoirs come with a pair of specially-made EK- PC Chassis Reservoir holders. These holders are meant to be installed directly on the computer chassis. M4 Nut If there are no appropriate mounting holes available, you may need to drill two (2) Ø4mm holes through a chassis panel with an electric power drill. -
Page 6: Recommended Reservoir Configuration
STEP 3 Once the reservoir is in place, use the enclosed 2.5mm Allen key to tighten the hex head screw to secure the reservoir. Do not apply too much force. Partially unscrew that same screw when removing the reservoir. Allen Key 2.5 mm M4 Holder Screw STEP 3 RECOMMENDED RESERVOIR CONFIGURATION... -
Page 7: Connecting The D-Rgb Led Strip
When using optional Inlet and Outlet ports, it is mandatory to use the enclosed EK-Extender G1/4 since these ports are recessed into the plastic reservoir bottom. Extender G1/4 CONNECTING THE D-RGB LED STRIP Plug the 3-pin connector from the reservoir D-RGB LED light into the D-RGB Header on the motherboard. -
Page 8: Testing The Loop
TESTING THE LOOP To make sure the installation of EK components was successful, we recommend you perform a 24-hour leak test. When your loop is complete and filled with coolant, connect the pump to a PSU outside of your system. Do not connect power to any of the other components. -
Page 9: Support And Service
SUPPORT AND SERVICE In case you need assistance, please contact: http://support.ekwb.com/ EKWB d.o.o. Pod lipami 18 1218 Komenda Slovenia - EU SOCIAL MEDIA EKWaterBlocks @EKWaterBlocks ekwaterblocks EKWBofficial ekwaterblocks...
