- Page 1 For EK-XLC Predator units | 1st revision, July 15th 2016 EK-XLC Predator 240/360 Push-Pull Addon INSTALLATION MANUAL...
- Page 2 All disclosures, notices and warranty conditions are being written on the EKWB website. Please read terms of use. This product is intended for installation Before you start using this product only by expert users. Please consult please follow these basic guide- with a qualifi...
-
Page 3: Contents Of The Package
CONTENTS OF THE PACKAGE Vardar F4-120ER fan M4x6 DIN7984 M4X10 DIN7984 2/3 pcs 8/12 pcs 3/4 pcs 2,5 mm Allen key Cable tie 1 pcs 3/4 pcs / 2 /... - Page 4 Y 2-fan splitter adapter Y 3-fan splitter adapter 1 pcs 1 pcs (only at 360 mm version) / 3 /...
- Page 5 The fans come with di erent ca- Cable lenght ble leads lenght. This is because every fan is intended for specifi c position on the Predator unit. The longer the cable, the further away from the fan splitter hub is fan meant to be installed.
- Page 6 PREPARING YOUR PREDATOR UNIT STEP 1: It is recommended to remove the Predator unit out of the chassis. You can leave the water block installed but must be careful not to pull/bend the tubing. That may result to leakage and damaged hardware. You can also unplug all the electrical connections from the predator unit in order to in- stall the fans comfortably.
- Page 7 INSTALLING ADDITIONAL FANS The additional two (With EK-XLC Predator 240) or three (With EK- XLC Predator 360) fans should be installed on the bottom side of the Airfl ow direction Predator unit. Do NOT install the additional fans on top of the stock ones.
- Page 8 In order to secure the fans Cable tie to the Predator chassis you M4x10 DIN should use four (4) M4x6 7984 Screw DIN 7984 screws with the enclosed Allen key for each fan unit. If you want to se- cure the cables to the Pred- ator unit you should use a cable tie along with longer –...
-
Page 9: Electrical Connections
In order to connect the fans you should take the enclosed fan splitter adapters. Please follow the instructions below, de- pending on the variant of EK-XLC Predator EK-XLC PREDATOR 240 STEP 1: Y 2-fan splitter adapter Connect the 2 female 4-pin headers from... - Page 10 EK-XLC PREDATOR 360 STEP 1: Connect the 3 female 4-pin headers from the fans with the male ones from the Y 3-fan splitter as shown on the picture. STEP 2: Disconnect one fan from the fan splitter hub located on the backside of EK-XLC Predator unit.
- Page 11 STEP 3: Prepare the Y 2-fan splitter adapter, female 4-pin connector, which you have discon- nected in previous step, and the female header from Y 3-fan splitter adapter. Con- nect the 2 female headers with the 2 male headers on the Y 2-fan splitter adapter. Y 2-fan splitter adapter STEP 4: Take the female 4-pin connector from the...
-
Page 12: Finalizing Installation
EK- XLC Predator installation manual (see QR code below). If you tend to have any questions please contact our support for assistance: http://support.ekwb.com/ EKWB d.o.o. Pod lipami 18 1218 Komenda Slovenia - EU / 11 /...
