To access one of the menu options below, press and hold the MENU
button. In the Option Menu use the ARROW buttons to scroll to the
desired option and press ENTER to select it.
IMPORTANT: The last test results will be lost when you start a
new test.

VIEW RESULTS

Scroll to VIEW RESULTS, and press ENTER. Use the ENTER and
BACK to scroll through the last test result, which will include the test
code.

PRINT RESULTS

The analyzer also has the ability to print the last test result using the
IR output at the top of the analyzer and the IR receiver of the printer
(below the MODE button).
IMPORTANT: If you will be using the printer for the first time,
charge the printer battery for 16 hours before beginning your
test session. Refer to the printer manual for more information.
With the printer on, align the IR transmitter on the top of the analyzer
with printer's IR receiver (below the MODE button). Press the menu
button and scroll to the PRINT RESULTS option by pressing the
ARROW buttons. When you are ready to print, press ENTER.
HINTS:
1. If the IR transmitter and receiver are not aligned, all the data
may not print. Press MENU to cancel the print job. Verify
alignment between the analyzer and printer, then try to print the
test results again.
2. It takes about 30 seconds to print all test results, which are
displayed simultaneously on the screen.

MENU OPTIONS

12
• •
