If you are unable to print after ensuring the analyzer is
functioning, the printer is on, the battery is good, and the IR
transmitter and receiver are aligned, check the printer manual for
further instructions or call Midtronics at 800-776-1995 for
assistance.
REPLACING THE ANALYZER BATTERY
The Celltron START+ uses a 9-volt battery (alkaline recommended)
to allow testing of batteries down to 1 volt as well as supply power
while the Option menu is active. When the internal battery requires
replacing, the analyzer will display LOW INTERNAL BATTERY,
REPLACE. You should change the battery as soon after the mes-
sage is displayed as possible.
Note: The analyzer will retain setup information while you change
the 9-volt battery.
IMPORTANT: The analyzer can test down to 5.5 volts when the
internal 9-volt battery is not functioning.
1.
Remove the cover to the battery door using a small screwdriver.
2.
Insert a 9-volt battery as shown below, making sure the positive
and negative terminals are positioned correctly.
3.
Put the back cover and tighten the screw.
18
•
•
