BATTERY PACK TEST RESULTS

The analyzer will display the open circuit voltage, the cranking amps
(units are based on the rating system you selected), and a decision
in the following format:
• GOOD BAT.PACK—The battery pack is in good shape when
compared with its rating while being compensated for cable and
connector resistance.
• CHECK BAT.PACK—After compensating for cable and
connector resistance, the battery pack is in poor shape when
compared with its rating. Check the connections and test the
batteries separately.

TESTING INDIVIDUAL BATTERIES

At the end of the Pack Test, the analyzer will give you the option to
test the batteries separately. If you choose YES, the analyzer will
prompt you through the steps of disconnecting, testing each battery,
and reconnecting the battery pack. If you select NO, the analyzer will
store the Battery Pack Test results. If you selected a Full System
Test, the analyzer will proceed to the Starting System Test.

INDIVIDUAL BATTERY TEST RESULTS

The analyzer will display the open circuit voltage, cranking amps
(units are based on the rating system selected by the user) and one
of the following decisions:
• GOOD BATTERY—The battery is in good condition. Return to
service.
• GOOD-RECHARGE—Fully charge the battery. Return to service.
• CHARGE & RETEST—Fully charge the battery, remove surface
charge, and retest. Failure to fully charge the battery before
retesting may cause false readings.
12.62 V 1685 CCA
GOOD BAT.PACK
7
• •
