int anaInCalib(int channel, int opmode,
int gaincode, int value1, float volts1,
int value2, float volts2);
Calibrates the response of the desired A/D converter channel as a linear function using the two conver-
sion points provided. Four values are calculated and placed into global tables _adcCalibS,
_adcCalibD, and adcCalibM to be later stored into simulated EEPROM using the function
anaInEEWr(). Each channel will have a linear constant and a voltage offset.
PARAMETERS
channel is the analog input channel number (0 to 7) corresponding to ADC_IN0 to ADC_IN7
opmode is the mode of operation:
SINGLE—single-ended input
DIFF—differential input
mAMP—milliamp input
channel
0
1
2
3
4
5
6
7
* Not accessible on Prototyping Board.
gaincode is the gain code of 0 to 7:
46
SINGLE
+AIN0
+AIN1
+AIN2
+AIN3
+AIN4
+AIN5
+AIN6
+AIN7
Gain Code Multiplier
0 ×1
1 ×2
2 ×4
3 ×5
4 ×8
5 ×10
6 ×16
7 ×20
* Applies to Prototyping Board.
DIFF
+AIN0 -AIN1
+AIN1 -AIN0*
+AIN2 -AIN3
+AIN3 -AIN2*
+AIN4 -AIN5
+AIN5 -AIN4*
+AIN6 -AIN7*
+AIN7 -AIN6*
Voltage Range
(V)
0–20
0–10
0–5
0–4
0–2.5
0–2
0–1.25
0–1
mAMP
*
+AIN0
+AIN1*
+AIN2*
+AIN3
+AIN4
+AIN5
+AIN6
+AIN7*
*
