Only suitable cable and line entries and blind plugs certi ed according to the ATEX/IECEx protection class may be used for the
introduction of cables (lines) - the diameters must correspond to the cables used.
Unused housing entries (threaded holes) which are intended for the use of cable and line entries must be sealed with suitable blind
plugs certi ed according to the ATEX/IECEx protection class. When selecting the correct cable and line entry, EN IEC 60079-14 must
also be observed. The cable and line entries as well as blind plugs must be suitable for an operating temperature of at least +80°C.
WARNING
Suitable products (cable entries, blind plugs) are available as accessories from ARIS, tailored to the ATEX/IECEx products. If requi-
red, these are loosely enclosed with the drive. The delivery is always unassembled.
Please note the correct assembly. The cable entries used must always be designed for the connecting cables and correspond to the
cable diameters.
3.3

Performance data

Voltage supply AC
Voltage supply DC
Max. power consumption
Torque
Actuating time
Motor type
!
ADVICE
ExTensor
DANGER! On the back of the drive, there is a blind plug to close the handwheel option for
equipment variants without a handwheel. This may not be removed or altered. See also
Chapter 6 - Handwheel section.
Another transport protection sticker is located on top of the drive hood to protect the sight
glass during transport / storage. This must also be removed prior to commissioning. Opera-
tion with the sticker or parts thereof is not permitted. Non-compliance can lead to serious
accidents and damage to property - The ATEX/IECEx approval of the device becomes void
in the event of non-compliance or misuse.
85...265 V AC (50/60 Hz)
24 V DC (±10%)
60 VA
5 Nm...500 Nm
1s/90°...150s/90°
BLDC
ARIS actuators type ExTensor correspond in their basic form (primary version) up to 40Nm
torque - without gear extensions, the EU type examination certi cate number IBExU22A-
TEX1066 X. - see appendix of these operating instructions. Variants with torques of
50 ... 500Nm (secondary versions) correspond to the primary version, but are supplemen-
ted by an externally mounted gear extension (planetary gear stage).
End position cutoff
Position feedback
Connection
Ambient temperature
IP protection class
Digital
Digital, contactless
Cable/wire entry: 3x M25x1.5
-20° C...+60° C
IP65/IP67
