ARIS ExTensor Original Declaration Of Incorporation With Manual page 21

Hyst. Start
Hyst. Stop
Stall-det.
Block-det.
RPM acc.
RPM red.
Add feature
POWR. MENU
Torque/Speed Selection of a torque/time combination
INFO MENU
Firmware
Hardware
Serial-No.
Features
On-time
Cycl. Count
Modules
Menu items in detail
MAIN MENU
Login
Enables selection of an access level. If a password has been stored, enter it here to proceed to further menu items.
Depending on the selected access level, single menu items may not be visible or adjustable.
If the login is missing, only the INFO MENU and the menu item LOGIN (in MAIN MENU) are visible.
The following users are selectable:
• User
• Service
• Manufacturer (ARIS only)
A logged in user can be logged out via the menu item "Logout".
ExTensor
Define start hysteresis
Define stop hysteresis
Settings for block detection
Settings for block detection near the end positions
Define acceleration ramp of actuator
Define break ramp of actuator
Entry of activation code for function extensions
Power Menu
for CCW resp. CW rotation
Information Menu
Indicates firmware revision
Indicates hardware revision
Indicates serial number of the electronics
Indicates unlocked actuator functions
Indicates operating hours of the actuator
Indicates number of starts of the actuator
Indicates connected modules/option boards
X
X
X
21
