Leg Installation; Initial Cleaning - MTI AUTOFRY -40C Operator's Manual

3.

Leg Installation.

•
The AutoFry is shipped with (4) ½-13 bolts installed in leg
plates. Remove the bolts before installing the legs. To
remove the shipping bolts, tilt the unit back while still on its
pallet and loosen by turning the bolt counterclockwise.
•
Install two of the adjustable legs by rotating them clockwise
until hand tight in the front two leg plates. Figure 2.
•
Tilt the unit forward and repeat for the rear two legs.
4.
Place the AutoFry on the counter.
•
Adjust the legs (as needed) to level the AutoFry.
•
Make sure that nothing is placed on top of the AutoFry which could
obstruct the exhaust system.
5.

Initial Cleaning.

•
Wash the oil pots, Teflon cook baskets, and the food exit chutes in warm soapy water
followed by a clear water rinse.
•
Remove the food entry chutes by turning the food chute knob counterclockwise. Figure 3A.
•
Separate the two-piece food entry chute and wash in warm soapy water followed by a clear
water rinse. Figure 3B.
6.
Sanitize the parts.
•
All parts must be sanitized.
•
Reassemble and reinstall the clean, dry parts.
63-0128 MTI-40C TS OM 11/23
AutoFry
MTI-40C Operator's Manual
Figure 3A Figure 3B
7
Figure 2
