Power - MTI AUTOFRY -40C Operator's Manual

12.
Install the Food Exit Chutes.
•
Slide the food exit chutes, flange side up, through the
cutout on the side of the AutoFry and slip the flange
over the edge of the interior wall. Figure 11.
•
Repeat on both sides of the unit.
13.
Install the Teflon Cook Basket.
•
Insert the flat end of the basket rod into the slot in the basket cam located on the back wall
of the cook chamber. Figure 12A.
•
Install the round end of the basket rod into the receiver clip on the inside front of the cook
chamber. Figure 12B.
Figure 12A
IMPORTANT
The completed installation will have the basket positioned
at an angle above the oil pot. Figure 13. This is normal.
Do not force the basket down into the oil pot or
damage to the basket motor will result.
When adding oil, remove the Teflon cook baskets. Never
use the basket as a rest for the oil container.
14.

Power.

•
Close and lock the main door.
•
Plug the AutoFry into the properly rated, grounded outlet.
You are now ready to start cooking!
63-0128 MTI-40C TS OM 11/23
AutoFry
MTI-40C Operator's Manual
10
Figure 11
Figure 12B
Figure 13
