Leg Installation; Initial Cleaning - MTI AUTOFRY -5LV Operator's Manual

3.

Leg Installation.

•
The AutoFry is shipped with (4) ½-13 bolts installed in leg plates.
Remove the bolts before installing the legs. To remove the
shipping bolts, tilt the unit back while still on its pallet and loosen
by turning the bolt counterclockwise.
•
Install two of the adjustable legs by rotating them clockwise until
hand tight in the front two leg plates. Figure 2.
•
Tilt the unit forward and repeat for the rear two legs.
4.
Place the AutoFry on the counter.
•
Adjust the legs (as needed) to level the AutoFry.
•
Make sure that nothing is placed on top of the AutoFry which could obstruct the exhaust
system.
5.

Initial Cleaning.

•
Wash the oil pot, Teflon cook basket, and the food exit chute in warm soapy water followed
by a clear water rinse.
•
Remove the food entry chute by turning the food chute knob counterclockwise. Figure 3A.
Figure 3A
•
Separate the two-piece food entry chute and wash in warm soapy water followed by a clear
water rinse. Figure 3B.
6.
Sanitize the parts.
•
All parts must be sanitized.
•
Reassemble and reinstall the clean, dry parts.
MTI-5LV OM 01/23
AutoFry
MTI-5LV Operator's Manual
7
63-0122
Figure 2
Figure 3B
