Goodrive880 Series Active Rectifier Hardware Manual

Appendix B Dimension drawings

202401 (V1.0)
Figure B-1 A3 structure dimensions (unit: mm)
436
Figure B-2 A4 structure dimensions (unit: mm)
436
95.3
Dimension drawings
50
4- 7.0
Back cut-out
dimensions
150
4- 7.0
Back cut-out
dimensions
76
