Goodrive880 Series Active Rectifier Hardware Manual
4.4 Electrical wiring
4.4.1 Main circuit wiring
4.4.2 A3&A4 cable connection
1.
A3 unit terminals
2.
A4 unit terminals
No.
Terminal name
1
202401 (V1.0)
Figure 4-9 A3 unit terminals
2
Figure 4-10 A4 unit terminals
+24E
COM
+24E
COM
①
+24E
24V auxiliary power terminal (The auxiliary power supply
must be isolated 24V.)
COM
Specification: 24Vdc±10% 1A
+24E
COM
+24VE
COM
1
3
PE
L1
L2
L3
②
③
PE
L3
L1
L2
Description
Electrical installation
43
