140 W HFB+PAG2S Solution Board (REF_140W_HFB_PAG2S) user
guide
Board overview
The waveform shown in
performance of the 140 W USB-C PD converter. This solution attains a power factor exceeding 0.9 for the entire
input voltage range at a 140 W load while surpassing 0.98 for an input voltage of 115 Vac and a 140 W load.
22
20
18
16
14
12
10
8
6
4
2
0
Figure 3 USB PD CV and CC performance at 115 Vac
User guide
Figure 3 illustrates the constant voltage (CV) and constant current (CC) modes of
1 2
Load(A)
Vout vs Iout
3 4 5
10
3.3V CV -- 1A CC
5V CV-- 1A CC
9V CV -- 1A CC
15V CV -- 1A CC
20V CV -- 1A CC
3.3V CV -- 3A CC
5V CV -- 3A CC
9V CV -- 3A CC
15V CV -- 3A CC
20V CV -- 3A CC
3.3V CV -- 5A CC
5V CV -- 5A CC
9V CV -- 5A CC
15V CV -- 5A CC
6
20V CV -- 5A CC
002-38685 Rev. *A
2024-01-29
