EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS
Evaluation Board

Preface

Scope and Purpose

This document describes the EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS and 1EDI3028AS evaluation
board PCB revision 1.1. Please also refer to the corresponding datasheet.

Intended Audience

This document is intended for engineers who develop applications.
User Manual
Please read the sections "Important notice" and "Warnings" at the end of this document
Rev 1.3
www.infineon.com
2023-11-24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EiceDRIVER 1EDI3025AS and is the answer not in the manual?

Questions and answers

Summary of Contents for Infineon EiceDRIVER 1EDI3025AS

  • Page 1: Preface

    PCB revision 1.1. Please also refer to the corresponding datasheet. Intended Audience This document is intended for engineers who develop applications. User Manual Please read the sections “Important notice” and “Warnings” at the end of this document Rev 1.3 www.infineon.com 2023-11-24...
  • Page 2: Table Of Contents

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 Table of contents Table of contents Preface ............................1 Scope and Purpose .......................... 1 Intended Audience .......................... 1 Table of contents ..........................2 Safety Instructions ......................... 3 Introduction .......................... 4 General Description ..........................4 EiceDRIVER™...
  • Page 3: Safety Instructions

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 1 Safety Instructions Safety Instructions ELECTRIC SHOCK HAZARD. Contact can cause an electric shock. If a voltage above 60 V is applied to the evaluation board, then only persons trained in working with voltages above 60 V are allowed to handle the evaluation board. In addition, ensure that hazardous live parts are not accessible and that accessible live parts are not hazardous.
  • Page 4: Introduction

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 2 Introduction Introduction General Description The EiceDRIVER™ gate driver 1EDI3025AS,1EDI3026AS, 1EDI3028AS evaluation board is a versatile evaluation platform. It features a half bridge configuration. There is the option to mount either the FF450R08A03P2 HybridPACK™...
  • Page 5: Eicedriverâ„¢ Gate Driver Overview

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 EiceDRIVER™ Gate driver overview There is a total of five different devices in this product family: 1EDI3035AS, 1EDI3036AS, 1EDI3038AS, 1EDI3025AS, 1EDI3026AS and 1EDI3028AS. Each family member implements a slightly different feature-set and is optimized to target different power switch technologies, whereas the power stage and safety concept is shared between all members.
  • Page 6: Operating Modes

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 Operating Modes The EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS and 1EDI3028AS offers different operating modes, see below. They provide diagnostic features and the ability to enter safe state in case of system failure. For more details, please refer to the datasheet.
  • Page 7 EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 Figure 2 Operating modes diagram 1EDI3026AS User Manual Rev 1.3 2023-11-24...
  • Page 8: Block Diagram

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 Block diagram 2.4.1 1EDI3025AS Figure 3 1EDI3025 block diagram User Manual Rev 1.3 2023-11-24...
  • Page 9: 1Edi3026As

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 2.4.2 1EDI3026AS Figure 4 1EDI3026 block diagram User Manual Rev 1.3 2023-11-24...
  • Page 10: 1Edi3028As

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 2.4.3 1EDI3028AS Figure 5 1EDI3028AS block diagram User Manual Rev 1.3 2023-11-24...
  • Page 11: Getting Started

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 3 Getting Started Getting Started It is recommended to use the Evaluation-Board with the FF450R08A03P2 HybridPACK™ DSC or the AIKQ120N75CP2 IGBT mounted. It can also be used in capacitive load emulation or with any other footprint compatible device [1206(3216)]. For load emulation place capacitors C22 and C7, see Figure 6, which are not placed by default.
  • Page 12: Evaluation Board

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 4 Evaluation Board Evaluation Board PCB Overview Figure 7 shows an overview of the EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board. A vertical line on the PCB marks the split between primary side and secondary side. The transformer TR1 provides the supply voltages for the secondary side of the gate drivers.
  • Page 13: Connectors

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 4 Evaluation Board Connectors There are connectors on the primary side and on the secondary side of the EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS and 1EDI3028AS evaluation board. The board requires a supply voltage of +15 V at the banana sockets on the primary side.
  • Page 14: Led Indicators

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 4 Evaluation Board Figure 10 Secondary Side Connectors LED Indicators LEDs on the EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board indicate board health and driver status, see Figure Dedicated NFLT_x and RDY_x indicator for each driver Primary side supply indicator on VCC Secondary side VCC indicator for each driver...
  • Page 15: Operating Conditions

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 4 Evaluation Board Operating conditions When using the 1EDI3025AS, 1EDI3026AS, 1EDI3038AS evaluation board the operating conditions of the board shall be valued. Note that the high voltage capability of the board is derived from the theoretical limit of the components on the board but not guaranteed or tested.
  • Page 16: Jumper Configuration

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 4 Evaluation Board Jumper configuration The EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board provides the following configuration options: Pullup or remote configuration of SI − Disable DESAT-/OCP-protection on high- or low-side −...
  • Page 17: Si1 And Si2 Pullup

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 4 Evaluation Board 4.5.1 SI1 and SI2 PULLUP For test-setups without HV-connections and without a second input voltage, set Jumper 1 and Jumper 2 in Position 2-3 to reset the driver by pressing the reset button. To change to PWM Enable state, press the reset button once after setting the jumpers.
  • Page 18: Si1 And Si2 Remote Reset

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 4 Evaluation Board 4.5.3 SI1 and SI2 Remote Reset For high voltage testing it is not advised to use the button S1 to reset and transition the device from PWM Disable to PWM Enable mode.
  • Page 19: Connect Desat And Ocp To Gnd

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 4 Evaluation Board For a defined power-down of both gate drivers, ramp-down the voltage on the +15V jack below 13.5V and thus put them into PWM Disable mode. Figure 16 SI1, SI2 Remote 4.5.4 Connect DESAT and OCP to GND Place Jumper 3 and Jumper 4 to connect the high side DESAT- and low side DESAT-signal to GND.
  • Page 20: Aip B And Sascb

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 4 Evaluation Board 4.5.5 and SASC There is also the option to measure the DC-Link voltage via the ADC of the low-side driver or to test the Secondary Active Short Circuit (SASC) functionality. Do not place Jumper 5 to measure DC-Link.
  • Page 21: Change Between 1Edi3025As, 1Edi3026As And 1Edi3028As

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 4 Evaluation Board Change between 1EDI3025AS, 1EDI3026AS and 1EDI3028AS If a change from driver variant x25AS to x26AS, x28AS or x26AS to x25AS, x28AS is desired, the resistors R7/R17 or R9/R19 need to be placed as follows: Table 6 Resistor Placement for x25AS, x26AS, x28AS on High Side Variant...
  • Page 22: Schematic And Layout

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 5 Schematic and Layout Schematic and Layout Schematic Figure 19 Driver schematic HS 1EDI3025AS, LS 1EDI3026AS User Manual Rev 1.3 2023-11-24...
  • Page 23 EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 5 Schematic and Layout Figure 20 Driver schematic HS 1EDI3028AS, LS 1EDI3028AS User Manual Rev 1.3 2023-11-24...
  • Page 24 EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 5 Schematic and Layout Figure 21 Primary and secondary supply schematic User Manual Rev 1.3 2023-11-24...
  • Page 25: Layout

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 5 Schematic and Layout Layout The EiceDRIVER™ gate driver 1EDI3025AS/1EDI3026AS evaluation board PCB consists of two layers: top and bottom. For ease of use there are no components placed on the bottom side. Figure 22 Assembly Top View Figure 23...
  • Page 26 EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 5 Schematic and Layout Figure 24 Bottom Layer User Manual Rev 1.3 2023-11-24...
  • Page 27: Bill Of Materials

    C0805C101K5GACAUTO Kemet C59, C60 C0603C104J3RAC Kemet D2, D5 STTH112UFY STMicroelectronics D7, D9, D10, D12, D13, D14, D16 PMEG4005AEAZ Nexperia SS14-E3/61T Vishay Semiconductor D11, D15 Diodes Inc. H3, H4, H5, H6 SJ-5382 (CLEAR) 1EDI3025AS Infineon Technologies User Manual Rev 1.3 2023-11-24...
  • Page 28 EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 6 Bill of materials 1EDI3026AS Infineon Technologies AUIR2085S International Rectifier TLE42644G Infineon Technologies J1, J2, J3 MKDSN 1,5/ 2-5,08 Phoenix Contact J4, J5, J6, J7, J8, J9 M7581-05 Harwin Inc. LED1, LED2, LED3...
  • Page 29 EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 6 Bill of materials CRCW060368K0FKEA Vishay-Dale R36, R45 CRCW0603820RFKEA Vishay-Dale R37, R38 CRCW120615R0FKEA Vishay-Dale RCWE1206R220FKEA Vishay-Dale R47, R48, R50, R52, R53 CRCW06032K00FKEA Vishay-Dale R54, R55 CRCW2010649KFKEF Vishay CRCW06034K32FKEA Vishay RC0603FR-07100KL Yageo CRCW060334K0FKEA Vishay CRCW06034K53FKEA...
  • Page 30 EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 6 Bill of materials X4, X17, X20 TSW-103-07-G-S Samtec X16, X31 973 582-101 Hirschmann Test & Measurement 973 582-100 Hirschmann Test & Measurement 2501-2-00-80-00-00-07-0 Mill-Max X21, X22 5-1634506-2 TE Connectivity User Manual Rev 1.3 2023-11-24...
  • Page 31: Restrictions

    This evaluation board offers limited features only for evaluation and testing of Infineon products. The evaluation board is neither an end product nor a finished appliance, nor is it intended or authorized by Infineon to be integrated into end products. The evaluation board may not be used in any production system.
  • Page 32: Revision History

    EiceDRIVER™ gate driver 1EDI3025AS, 1EDI3026AS, 1EDI3028AS evaluation board Z8F80327692 Revision history Revision history Document Date Description of changes revision 2022-07-13 Created initial draft 2022-08-12 Updated schematics and layout, BOM Minor editorial changes 2022-08-25 Chapter 4.5.3 updated and expanded 2023-11-24 All chapters updated to reflect new board revision 2024-04-16 Added 1EDI3028AS board variant User Manual...
  • Page 33: Disclaimer

    For information on the types Published by characteristics (“Beschaffenheitsgarantie”) . in question, please contact your nearest Infineon Technologies office. Infineon Technologies AG With respect to any examples, hints or any typical...
