Bose ControlSpace EX-1280C Service Manual page 78

FB401 IND, 1K, 25%, 0603
FB402 0 OHM, 1A, 0603
FB450 IND, 1K, 25%, 0603
FB451 IND, 1K, 25%, 0603
FB452 0 OHM, 1A, 0603
Reference
Designator
D100 BAV99LT1G, SOT-23
D101 BAV99LT1G, SOT-23
D150 BAV99LT1G, SOT-23
D151 BAV99LT1G, SOT-23
D200 BAV99LT1G, SOT-23
D201 BAV99LT1G, SOT-23
D250 BAV99LT1G, SOT-23
D251 BAV99LT1G, SOT-23
D300 BAV99LT1G, SOT-23
D301 BAV99LT1G, SOT-23
D350 BAV99LT1G, SOT-23
D351 BAV99LT1G, SOT-23
D400 BAV99LT1G, SOT-23
D401 BAV99LT1G, SOT-23
D450 BAV99LT1G, SOT-23
D451 BAV99LT1G, SOT-23
D850 BAV70, 235, SOT-23
D851 BAV70, 235, SOT-23
D852 BAV70, 235, SOT-23
D853 BAV70, 235, SOT-23
D854 BAV99LT1G, SOT-23
D900 BAV70, 235, SOT-23
Reference
Designator
Q100 MOSFET, N-CH, 2N7002K-T1-E3, SOT-23
Q101 MOSFET, N-CH, 2N7002K-T1-E3, SOT-23
Q102 MOSFET, N-CH, 2N7002K-T1-E3, SOT-23
Q103 MOSFET, N-CH, 2N7002K-T1-E3, SOT-23
Q104 MOSFET, N-CH, 2N7002K-T1-E3, SOT-23
Q105 MOSFET, N-CH, 2N7002K-T1-E3, SOT-23
Q150 MOSFET, N-CH, 2N7002K-T1-E3, SOT-23
Q151 MOSFET, N-CH, 2N7002K-T1-E3, SOT-23
Q152 MOSFET, N-CH, 2N7002K-T1-E3, SOT-23
Q153 MOSFET, N-CH, 2N7002K-T1-E3, SOT-23
OUTPUT PCB PART LIST
Inductors (continued)
Diodes
Description
Transistors
Description
78
Taiyo Yud BK1608HS102-T
KOA RK73Z1JTTD
Taiyo Yud BK1608HS102-T
Taiyo Yud BK1608HS102-T
KOA RK73Z1JTTD
Vendor Vendor Part Number
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
ON Semi BAV99LT1G
NXP BAV70,235
NXP BAV70,235
NXP BAV70,235
NXP BAV70,235
ON Semi BAV99LT1G
NXP BAV70,235
Vendor Vendor Part Number
Vishay 2N7002K-T1-E3
Vishay 2N7002K-T1-E3
Vishay 2N7002K-T1-E3
Vishay 2N7002K-T1-E3
Vishay 2N7002K-T1-E3
Vishay 2N7002K-T1-E3
Vishay 2N7002K-T1-E3
Vishay 2N7002K-T1-E3
Vishay 2N7002K-T1-E3
Vishay 2N7002K-T1-E3
Note
Note
