Oled Pcb Part List - Bose ControlSpace EX-1280C Service Manual

Reference
Designator
R1 39.2K, 1/10W, 1%, 0402, SM
R2 4.32K, 1/10W, 1%, 0603, SM
R3 10.0K, 1/10W, 1%, 0402
R4 10.0K, 1/10W, 1%, 0402
R5 10.0K, 1/10W, 1%, 0402
R6 4.7K, 1/10W, 5%, 0603
R8 4.7K, 1/10W, 5%, 0603
R9 4.7K, 1/10W, 5%, 0603
R10 10.0K, 1/10W, 1%, 0402
R12 681 OHM, 1/10W, 1%, 0603
R14 4.7K, 1/10W, 5%, 0603
R15 4.7K, 1/10W, 5%, 0603
R16 10.0K, 1/10W, 1%, 0402
R17 10.0K, 1/10W, 1%, 0402
R18 10.0K, 1/10W, 1%, 0402
Reference
Designator
C1 CER, 4.7UF, 25V, 20%, X5R, 0805
C2 CER, 0.1UF, 25V, 10%, X7R, 0402
C3 ELYT, ALUM, 47UF, 25V, 20%, SM
C4 CER, 0.1UF, 25V, 10%, X7R, 0402
C5 ELYT, ALUM, 47UF, 25V, 20%, SM
C6 CER, 4.7UF, 25V, 20%, X5R, 0805
C7 CER, 0.1UF, 25V, 10%, X7R, 0402
C8 CER, 0.1UF, 25V, 10%, X7R, 0402
C9 ELYT, ALUM, 47UF, 25V, 20%, SM
C10 CER, 0.1UF, 25V, 10%, X7R, 0402
C11 CER, 0.1UF, 25V, 10%, X7R, 0402
C12 CER, 0.1UF, 25V, 10%, X7R, 0402
C13 CER, 0.1UF, 25V, 10%, X7R, 0402
C14 ELYT, ALUM, 47UF, 25V, 20%, SM
C15 CER, 0.1UF, 25V, 10%, X7R, 0402
Reference
Designator
D1 215MA, 70V, DUAL, SERIES, SOT-23-3
D2 215MA, 70V, DUAL, SERIES, SOT-23-3
D3 215MA, 70V, DUAL, SERIES, SOT-23-3
D4 215MA, 70V, DUAL, SERIES, SOT-23-3
D5 215MA, 70V, DUAL, SERIES, SOT-23-3

OLED PCB PART LIST

Resistors
Description
Capacitors
Description
Diodes
Description
100
Vendor Vendor Part Number
PANASONIC ERJ-2RKF3922X
PANASONIC ERJ-3EKF4321V
PANASONIC ERJ-2RKF1002X
PANASONIC ERJ-2RKF1002X
PANASONIC ERJ-2RKF1002X
PANASONIC ERJ-3GEYJ472V
PANASONIC ERJ-3GEYJ472V
PANASONIC ERJ-3GEYJ472V
PANASONIC ERJ-2RKF1002X
PANASONIC ERJ-3EKF6810V
PANASONIC ERJ-3GEYJ472V
PANASONIC ERJ-3GEYJ472V
PANASONIC ERJ-2RKF1002X
PANASONIC ERJ-2RKF1002X
PANASONIC ERJ-2RKF1002X
Vendor Vendor Part Number
MURATA GRM21BR61E475MA12L
TDK CGA2B3X7R1E104K
PANASONIC EEE-1EA470WP
TDK CGA2B3X7R1E104K
PANASONIC EEE-1EA470WP
MURATA GRM21BR61E475MA12L
TDK CGA2B3X7R1E104K
TDK CGA2B3X7R1E104K
PANASONIC EEE-1EA470WP
TDK CGA2B3X7R1E104K
TDK CGA2B3X7R1E104K
TDK CGA2B3X7R1E104K
TDK CGA2B3X7R1E104K
PANASONIC EEE-1EA470WP
TDK CGA2B3X7R1E104K
Vendor Vendor Part Number
ON SEMI BAV99LT1G
ON SEMI BAV99LT1G
ON SEMI BAV99LT1G
ON SEMI BAV99LT1G
ON SEMI BAV99LT1G
Note
Note
Note
