Bose ControlSpace EX-1280C Service Manual page 44

Reference
Designator
R1555 200K, 1/10W, 0603, 1%
R1556 0 OHM, 1A, 0603
R1557 0 OHM, 1A, 0603
R1558 10K, 1/10W, 0603, 1%
R1559 39K, 1/10W, 0603, 1%
R1560 39K, 1/10W, 0603, 1%
R1561 10K, 1/10W, 0603, 1%
R1563 3.3K, 1/10W, 0603, 1%
R1564 3.3K, 1/10W, 0603, 1%
R1565 220 OHM, 1/10W, 0603, 1%
R1566 820 OHM, 1/10W, 0603, 1%
R1567 220 OHM, 1/10W, 0603, 1%
R1568 820 OHM, 1/10W, 0603, 1%
R1569 IND82.5 OHM, 1/10W, 0603, 1%
R1570 19.1 OHM, 1/10W, 0603, 1%
R1571 82.5 OHM, 1/10W, 0603, 1%
R1572 19.1 OHM, 1/10W, 0603, 1%
R1573 0 OHM, 1A, 0603
R1600 1.91K, 1/10W, 0603, 1%
R1601 1.91K, 1/10W, 0603, 1%
R1602 1.91K, 1/10W, 0603, 1%
R1603 1.91K, 1/10W, 0603, 1%
R1604 11.3K, 1/10W, 0603, 1%
R1605 4.99K, 1/10W, 0603, 1%, T&R
R1606 4.99K, 1/10W, 0603, 1%, T&R
R1607 4.99K, 1/10W, 0603, 1%, T&R
R1608 330 OHM, 1/10W, 0603, 1%
R1609 4.99K, 1/10W, 0603, 1%, T&R
R1610 330 OHM, 1/10W, 0603, 1%
R1611 330 OHM, 1/10W, 0603, 1%
R1612 330 OHM, 1/10W, 0603, 1%
R1613 91 OHM, 1/10W, 0603, 1%
R1614 91 OHM, 1/10W, 0603, 1%
R1615 91 OHM, 1/10W, 0603, 1%
R1616 91 OHM, 1/10W, 0603, 1%
R1617 2.7K, 1/10W, 0603, 1%
R1618 2.7K, 1/10W, 0603, 1%
R1650 1.91K, 1/10W, 0603, 1%
R1651 1.91K, 1/10W, 0603, 1%
R1652 1.91K, 1/10W, 0603, 1%
R1653 1.91K, 1/10W, 0603, 1%
R1654 11.3K, 1/10W, 0603, 1%
R1655 4.99K, 1/10W, 0603, 1%, T&R
INPUT PCB PART LIST
Resistors (continued)
Description
44
Vendor Vendor Part Number
KOA RK73H1JTTD2003F
KOA RK73Z1JTTD
KOA RK73Z1JTTD
KOA RK73H1JTTD1002F
KOA RK73H1JTTD3902F
KOA RK73H1JTTD3902F
KOA RK73H1JTTD1002F
KOA RK73H1JTTD3301F
KOA RK73H1JTTD3301F
KOA RK73H1JTTD2200F
KOA RK73H1JTTD8200F
KOA RK73H1JTTD2200F
KOA RK73H1JTTD8200F
KOA RK73H1JTTD82R5F
KOA RK73H1JTTD19R1F
KOA RK73H1JTTD82R5F
KOA RK73H1JTTD19R1F
KOA RK73Z1JTTD
KOA RK73H1JTTD1911F
KOA RK73H1JTTD1911F
KOA RK73H1JTTD1911F
KOA RK73H1JTTD1911F
KOA RK73H1JTTD1132F
KOA RK73H1JTTD4991F
KOA RK73H1JTTD4991F
KOA RK73H1JTTD4991F
KOA RK73H1JTTD3300F
KOA RK73H1JTTD4991F
KOA RK73H1JTTD3300F
KOA RK73H1JTTD3300F
KOA RK73H1JTTD3300F
KOA RK73H1JTTD91R0F
KOA RK73H1JTTD91R0F
KOA RK73H1JTTD91R0F
KOA RK73H1JTTD91R0F
KOA RK73H1JTTD2701F
KOA RK73H1JTTD2701F
KOA RK73H1JTTD1911F
KOA RK73H1JTTD1911F
KOA RK73H1JTTD1911F
KOA RK73H1JTTD1911F
KOA RK73H1JTTD1132F
KOA RK73H1JTTD4991F
Note
