Bose ControlSpace EX-1280C Service Manual page 43

Reference
Designator
R1458 10K, 1/10W, 0603, 1%
R1459 39K, 1/10W, 0603, 1%
R1460 39K, 1/10W, 0603, 1%
R1461 10K, 1/10W, 0603, 1%
R1463 3.3K, 1/10W, 0603, 1%
R1464 3.3K, 1/10W, 0603, 1%
R1465 220 OHM, 1/10W, 0603, 1%
R1466 820 OHM, 1/10W, 0603, 1%
R1467 220 OHM, 1/10W, 0603, 1%
R1468 820 OHM, 1/10W, 0603, 1%
R1469 IND82.5 OHM, 1/10W, 0603, 1%
R1470 19.1 OHM, 1/10W, 0603, 1%
R1471 IND82.5 OHM, 1/10W, 0603, 1%
R1472 19.1 OHM, 1/10W, 0603, 1%
R1473 0 OHM, 1A, 0603
R1500 330K, 1/10W, 0603, 1%
R1501 100 OHM, 1/8W, 0805, 1%
R1502 20K, 1/10W, 0603, 1%, T&R
R1503 6.8K, 1/2W, 1210, 1%
R1504 6.8K, 1/2W, 1210, 1%
R1505 200K, 1/10W, 0603, 1%
R1506 0 OHM, 1A, 0603
R1507 0 OHM, 1A, 0603
R1508 10K, 1/10W, 0603, 1%
R1509 39K, 1/10W, 0603, 1%
R1510 39K, 1/10W, 0603, 1%
R1511 10K, 1/10W, 0603, 1%
R1513 3.3K, 1/10W, 0603, 1%
R1514 3.3K, 1/10W, 0603, 1%
R1515 220 OHM, 1/10W, 0603, 1%
R1516 820 OHM, 1/10W, 0603, 1%
R1517 220 OHM, 1/10W, 0603, 1%
R1518 820 OHM, 1/10W, 0603, 1%
R1519 IND82.5 OHM, 1/10W, 0603, 1%
R1520 19.1 OHM, 1/10W, 0603, 1%
R1521 IND82.5 OHM, 1/10W, 0603, 1%
R1522 19.1 OHM, 1/10W, 0603, 1%
R1523 0 OHM, 1A, 0603
R1550 330K, 1/10W, 0603, 1%
R1551 100 OHM, 1/8W, 0805, 1%
R1552 20K, 1/10W, 0603, 1%, T&R
R1553 6.8K, 1/2W, 1210, 1%
R1554 6.8K, 1/2W, 1210, 1%
INPUT PCB PART LIST
Resistors (continued)
Description
43
Vendor Vendor Part Number
KOA RK73H1JTTD1002F
KOA RK73H1JTTD3902F
KOA RK73H1JTTD3902F
KOA RK73H1JTTD1002F
KOA RK73H1JTTD3301F
KOA RK73H1JTTD3301F
KOA RK73H1JTTD2200F
KOA RK73H1JTTD8200F
KOA RK73H1JTTD2200F
KOA RK73H1JTTD8200F
KOA RK73H1JTTD82R5F
KOA RK73H1JTTD19R1F
KOA RK73H1JTTD82R5F
KOA RK73H1JTTD19R1F
KOA RK73Z1JTTD
Panasonic ERJ-3EKF3303V
Yageo RC0805FR-07100RL
KOA RK73H1JTTD2002F
Panasonic ERJ-14NF6801U
Panasonic ERJ-14NF6801U
KOA RK73H1JTTD2003F
KOA RK73Z1JTTD
KOA RK73Z1JTTD
KOA RK73H1JTTD1002F
KOA RK73H1JTTD3902F
KOA RK73H1JTTD3902F
KOA RK73H1JTTD1002F
KOA RK73H1JTTD3301F
KOA RK73H1JTTD3301F
KOA RK73H1JTTD2200F
KOA RK73H1JTTD8200F
KOA RK73H1JTTD2200F
KOA RK73H1JTTD8200F
KOA RK73H1JTTD82R5F
KOA RK73H1JTTD19R1F
KOA RK73H1JTTD82R5F
KOA RK73H1JTTD19R1F
KOA RK73Z1JTTD
Panasonic ERJ-3EKF3303V
Yageo RC0805FR-07100RL
KOA RK73H1JTTD2002F
Panasonic ERJ-14NF6801U
Panasonic ERJ-14NF6801U
Note
