Bose ControlSpace EX-1280C Service Manual page 21

Reference
Designator
RN4 RES NET, ISO, 22, 5%, 62.5MW, 1606
RN5 RES NET, ISO, 33, 5%, 62.5MW, 1606
RN6 RES NET, ISO, 33, 5%, 62.5MW, 1606
RN7 RES NET, ISO, 22, 5%, 62.5MW, 1606
RN8 RES NET, ISO, 22, 5%, 62.5MW, 1606
RN9 RES NET, ISO, 22, 5%, 62.5MW, 1606
Reference
Designator
C1 NPO 22PF 50V +/-5% 0402 ROHS
C2 NPO 22PF 50V +/-5% 0402 ROHS
C3 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C4 TANT 68UF 6.3V 10% 1206
C5 TANT 33UF 6.3V 20% 1206
C6 TANT 33UF 6.3V 20% 1206
C7 CER, 10UF, 25V, 10%, X5R, 0805, SM
C8 CER, 10UF, 25V, 10%, X5R, 0805, SM
C9 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C10 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C11 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C12 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C13 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C14 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C15 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C16 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C17 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C18 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C19 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C20 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C21 NPO 22PF 50V +/-5% 0402 ROHS
C22 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C23 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C24 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C25 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C26 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C27 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C28 NPO 22PF 50V +/-5% 0402 ROHS
C29 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
C30 X7R 10NF 25V +/-10% 0402 ROHS
C31 X7R 10NF 25V +/-10% 0402 ROHS
C32 X7R 10NF 25V +/-10% 0402 ROHS
C33 CER, 0.1UF, 50V, 10%, X7R, 0402, SM
MAIN DSP PCB PART LIST
Resistor Networks (continued)
Description
Capacitors
Description
Vendor
ROHM
ROHM
ROHM
ROHM
ROHM
ROHM
Vendor
MURATA
MURATA
TDK
KEMET
KEMET
KEMET
MURATA
MURATA
TDK
TDK
TDK
TDK
TDK
TDK
TDK
TDK
TDK
TDK
TDK
TDK
MURATA
TDK
TDK
TDK
TDK
TDK
TDK
MURATA
TDK
MURATA
MURATA
MURATA
TDK
21
Vendor Part Number
MNR18ERAPJ220
MNR18ERAPJ330
MNR18ERAPJ330
MNR18ERAPJ220
MNR18ERAPJ220
MNR18ERAPJ220
Vendor Part Number
GRM1555C1H220JA01D
GRM1555C1H220JA01D
C1005X7R1H104K050BB
T491A686K006AT
T491A336M006AT
T491A336M006AT
GRM21BR61E106KA73L
GRM21BR61E106KA73L
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
GRM1555C1H220JA01D
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
C1005X7R1H104K050BB
GRM1555C1H220JA01D
C1005X7R1H104K050BB
GRM155R71E103KA01D
GRM155R71E103KA01D
GRM155R71E103KA01D
C1005X7R1H104K050BB
Note
Note
