Bose ControlSpace EX-1280C Service Manual page 73

Reference
Designator
C404 NPO, 22PF, 50V, 5%, 0603
C405 NPO, 22PF, 50V, 5%, 0603
C406 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C407 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C408 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C409 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C410 NPO, 3.6NF, 50V, 5%, 0603
C411 NPO, 3.6NF, 50V, 5%, 0603
C412 E CAP, 33UF, 25V, 20%, 55C, T&R
C413 E CAP, 33UF, 25V, 20%, 55C, T&R
C414 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C415 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C452 NPO, 22PF, 50V, 5%, 0603
C453 NPO, 22PF, 50V, 5%, 0603
C454 NPO, 22PF, 50V, 5%, 0603
C455 NPO, 22PF, 50V, 5%, 0603
C456 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C457 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C458 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C459 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C460 NPO, 3.6NF, 50V, 5%, 0603
C461 NPO, 3.6NF, 50V, 5%, 0603
C462 E CAP, 33UF, 25V, 20%, 55C, T&R
C463 E CAP, 33UF, 25V, 20%, 55C, T&R
C464 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C465 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C500 E CAP, 22UF, 6.3V, 20%, 55C, T&R
C501 E CAP, 22UF, 6.3V, 20%, 55C, T&R
C502 E CAP, 22UF, 6.3V, 20%, 55C, T&R
C503 E CAP, 22UF, 6.3V, 20%, 55C, T&R
C504 NPO, 1.8NF, 50V, 5%, 0603
C505 NPO, 1.8NF, 50V, 5%, 0603
C506 NPO, 1.8NF, 50V, 5%, 0603
C507 NPO, 1.8NF, 50V, 5%, 0603
C508 COG, 0.012UF, 25V, 5%, 0603
C509 COG, 0.012UF, 25V, 5%, 0603
C510 COG, 0.012UF, 25V, 5%, 0603
C511 COG, 0.012UF, 25V, 5%, 0603
C512 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C513 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C514 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C515 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C516 NPO, 3.6NF, 50V, 5%, 0603
OUTPUT PCB PART LIST
Capacitors (continued)
Description
73
Vendor Vendor Part Number
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM1885C1H362JA01D
Murata GRM1885C1H362JA01D
Panasonic EEE-FT1E330AR
Panasonic EEE-FT1E330AR
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM1885C1H362JA01D
Murata GRM1885C1H362JA01D
Panasonic EEE-FT1E330AR
Panasonic EEE-FT1E330AR
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Nichicon UWT0J220MCL1GB
Nichicon UWT0J220MCL1GB
Nichicon UWT0J220MCL1GB
Nichicon UWT0J220MCL1GB
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Kemet C0603C123J3GACTU
Kemet C0603C123J3GACTU
Kemet C0603C123J3GACTU
Kemet C0603C123J3GACTU
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM1885C1H362JA01D
Note
