Bose ControlSpace EX-1280C Service Manual page 74

Reference
Designator
C517 NPO, 3.6NF, 50V, 5%, 0603
C518 NPO, 3.6NF, 50V, 5%, 0603
C519 NPO, 3.6NF, 50V, 5%, 0603
C520 NPO, 1.8NF, 50V, 5%, 0603
C521 NPO, 1.8NF, 50V, 5%, 0603
C522 NPO, 1.8NF, 50V, 5%, 0603
C523 NPO, 1.8NF, 50V, 5%, 0603
C524 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C525 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C526 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C527 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C550 E CAP, 22UF, 6.3V, 20%, 55C, T&R
C551 E CAP, 22UF, 6.3V, 20%, 55C, T&R
C552 E CAP, 22UF, 6.3V, 20%, 55C, T&R
C553 E CAP, 22UF, 6.3V, 20%, 55C, T&R
C554 NPO, 1.8NF, 50V, 5%, 0603
C555 NPO, 1.8NF, 50V, 5%, 0603
C556 NPO, 1.8NF, 50V, 5%, 0603
C557 NPO, 1.8NF, 50V, 5%, 0603
C558 COG, 0.012UF, 25V, 5%, 0603
C559 COG, 0.012UF, 25V, 5%, 0603
C560 COG, 0.012UF, 25V, 5%, 0603
C561 COG, 0.012UF, 25V, 5%, 0603
C562 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C563 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C564 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C565 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C566 NPO, 3.6NF, 50V, 5%, 0603
C567 NPO, 3.6NF, 50V, 5%, 0603
C568 NPO, 3.6NF, 50V, 5%, 0603
C569 NPO, 3.6NF, 50V, 5%, 0603
C570 NPO, 1.8NF, 50V, 5%, 0603
C571 NPO, 1.8NF, 50V, 5%, 0603
C572 NPO, 1.8NF, 50V, 5%, 0603
C573 NPO, 1.8NF, 50V, 5%, 0603
C574 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C575 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C576 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C577 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C600 E CAP, 22UF, 6.3V, 20%, 55C, T&R
C601 E CAP, 22UF, 6.3V, 20%, 55C, T&R
C602 E CAP, 22UF, 6.3V, 20%, 55C, T&R
C603 E CAP, 22UF, 6.3V, 20%, 55C, T&R
OUTPUT PCB PART LIST
Capacitors (continued)
Description
74
Vendor Vendor Part Number
Murata GRM1885C1H362JA01D
Murata GRM1885C1H362JA01D
Murata GRM1885C1H362JA01D
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Nichicon UWT0J220MCL1GB
Nichicon UWT0J220MCL1GB
Nichicon UWT0J220MCL1GB
Nichicon UWT0J220MCL1GB
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Kemet C0603C123J3GACTU
Kemet C0603C123J3GACTU
Kemet C0603C123J3GACTU
Kemet C0603C123J3GACTU
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM1885C1H362JA01D
Murata GRM1885C1H362JA01D
Murata GRM1885C1H362JA01D
Murata GRM1885C1H362JA01D
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Nichicon UWT0J220MCL1GB
Nichicon UWT0J220MCL1GB
Nichicon UWT0J220MCL1GB
Nichicon UWT0J220MCL1GB
Note
