Reference
Designator
FB4
FERR BEAD, 0.8A, 150 OHM, 0805
FB5
FERR BEAD, 0.8A, 150 OHM, 0805
FB6
FERR BEAD, 0.8A, 150 OHM, 0805
FB7
FERR BEAD, 0.8A, 150 OHM, 0805
FB8
FERR BEAD, 0.8A, 150 OHM, 0805
FB10
FERR 50 OHM 3500MA 1206
FB11
FERR 50 OHM 3500MA 1206
FB12
FERR BEAD, 120 OHM, 3A, 0603
FB13
FERR BEAD, 120 OHM, 3A, 0603
FB14
FERR BEAD, 120 OHM, 3A, 0603
FB15
FERR 3A 80 OHM 1206 SMD
FB16
FERR BEAD, 220 OHM, 0.5A, 0603, SM
Reference
Designator
FC1
FILTER HIGH FREQ 2200PF 0805
FC2
FILTER HIGH FREQ 2200PF 0805
FC3
FILTER HIGH FREQ 2200PF 0805
FC4
FILTER HIGH FREQ 2200PF 0805
FC5
FILTER HIGH FREQ 2200PF 0805
FC6
FILTER HIGH FREQ 2200PF 0805
FC7
FILTER HIGH FREQ 2200PF 0805
FC8
FILTER HIGH FREQ 2200PF 0805
FC9
FILTER HIGH FREQ 2200PF 0805
FC10
FILTER HIGH FREQ 2200PF 0805
FC11
FILTER HIGH FREQ 2200PF 0805
FC12
FILTER HIGH FREQ 2200PF 0805
FC13
FILTER HIGH FREQ 2200PF 0805
FC14
FILTER HIGH FREQ 2200PF 0805
Reference
Designator
D1
TVS 6-CH 10UQFN
D2
SCHOTTKY 40V 100MA SMINI
D3
SCHOTTKY 40V 100MA SMINI
D4
TVS 5VWM 17VC SOT23-6
D5
TVS 5VWM 17VC SOT23-6
D6
TVS 5VWM 17VC SOT23-6
D7
TVS 5VWM 17VC SOT23-6
D8
TVS 5VWM 17VC SOT23-6
D9
TVS 5VWM 17VC SOT23-6
MAIN DSP PCB PART LIST
Ferrite Beads (continued)
Description
Filters
Description
Diodes
Description
Vendor
LAIRD-SIGNAL
LAIRD-SIGNAL
LAIRD-SIGNAL
LAIRD-SIGNAL
LAIRD-SIGNAL
MURATA
MURATA
MURATA
MURATA
MURATA
LAIRD-SIGNAL
MURATA
Vendor
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
Vendor
TEXAS INST.
TOSHIBA
TOSHIBA
ST MICRO
ST MICRO
ST MICRO
ST MICRO
ST MICRO
ST MICRO
33
Vendor Part Number
LI0805H151R-10
LI0805H151R-10
LI0805H151R-10
LI0805H151R-10
LI0805H151R-10
BLM31PG500SN1L
BLM31PG500SN1L
BLM18SG121TN1D
BLM18SG121TN1D
BLM18SG121TN1D
HI1206N800R-10
BLM18AG221SN1
Vendor Part Number
NFM21CC222R1H3D
NFM21CC222R1H3D
NFM21CC222R1H3D
NFM21CC222R1H3D
NFM21CC222R1H3D
NFM21CC222R1H3D
NFM21CC222R1H3D
NFM21CC222R1H3D
NFM21CC222R1H3D
NFM21CC222R1H3D
NFM21CC222R1H3D
NFM21CC222R1H3D
NFM21CC222R1H3D
NFM21CC222R1H3D
Vendor Part Number
TPD6E001RSER
1SS294,LF
1SS294,LF
DVIULC6-4SC6
DVIULC6-4SC6
DVIULC6-4SC6
DVIULC6-4SC6
DVIULC6-4SC6
DVIULC6-4SC6
Note
Note
Note
