Bose ControlSpace EX-1280C Service Manual page 71

Reference
Designator
C102 NPO, 22PF, 50V, 5%, 0603
C103 NPO, 22PF, 50V, 5%, 0603
C104 NPO, 22PF, 50V, 5%, 0603
C105 NPO, 22PF, 50V, 5%, 0603
C106 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C107 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C108 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C109 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C110 NPO, 3.6NF, 50V, 5%, 0603
C111 NPO, 3.6NF, 50V, 5%, 0603
C112 E CAP, 33UF, 25V, 20%, 55C, T&R
C113 E CAP, 33UF, 25V, 20%, 55C, T&R
C114 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C115 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C152 NPO, 22PF, 50V, 5%, 0603
C153 NPO, 22PF, 50V, 5%, 0603
C154 NPO, 22PF, 50V, 5%, 0603
C155 NPO, 22PF, 50V, 5%, 0603
C156 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C157 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C158 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C159 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C160 NPO, 3.6NF, 50V, 5%, 0603
C161 NPO, 3.6NF, 50V, 5%, 0603
C162 E CAP, 33UF, 25V, 20%, 55C, T&R
C163 E CAP, 33UF, 25V, 20%, 55C, T&R
C164 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C165 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C202 NPO, 22PF, 50V, 5%, 0603
C203 NPO, 22PF, 50V, 5%, 0603
C204 NPO, 22PF, 50V, 5%, 0603
C205 NPO, 22PF, 50V, 5%, 0603
C206 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C207 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C208 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C209 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C210 NPO, 3.6NF, 50V, 5%, 0603
C211 NPO, 3.6NF, 50V, 5%, 0603
C212 E CAP, 33UF, 25V, 20%, 55C, T&R
C213 E CAP, 33UF, 25V, 20%, 55C, T&R
C214 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C215 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C252 NPO, 22PF, 50V, 5%, 0603
OUTPUT PCB PART LIST
Capacitors
Description
71
Vendor Vendor Part Number
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM1885C1H362JA01D
Murata GRM1885C1H362JA01D
Panasonic EEE-FT1E330AR
Panasonic EEE-FT1E330AR
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM1885C1H362JA01D
Murata GRM1885C1H362JA01D
Panasonic EEE-FT1E330AR
Panasonic EEE-FT1E330AR
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM1885C1H362JA01D
Murata GRM1885C1H362JA01D
Panasonic EEE-FT1E330AR
Panasonic EEE-FT1E330AR
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM1885C1H220JA01D
Note
