Bose ControlSpace EX-1280C Service Manual page 34

Reference
Designator
D10 4CH ESD SOL W/CLAMP 6SON
D11 4CH ESD SOL W/CLAMP 6SON
D12 TVS SC70-3
D13 TVS 5VWM SMD
D14 TVS 5VWM SMD
D15 TVS 5VWM SMD
D16 TVS 5VWM SMD
D17 TVS 5VWM SMD
D18 SCHOTTKY 40V 100MA SMINI
D19 SCHOTTKY 40V 100MA SMINI
D20 SCHOTTKY 40V 100MA SMINI
D21 SCHOTTKY 40V 100MA SMINI
D22 SCHOTTKY 40V 100MA SMINI
D22 SCHOTTKY 40V 100MA SMINI
D23 TVS 24VWM SMD
D24 TVS 24VWM SMD
D25 TVS 24VWM SMD
D26 TVS 24VWM SMD
D27 TVS 24VWM SMD
D28 TVS 5VWM 17VC SOT23-6
D29 SCHOTTKY 40V 100MA SMINI
D30 SCHOTTKY 40V 100MA SMINI
D31 SCHOTTKY 40V 100MA SMINI
D32 SCHOTTKY 40V 100MA SMINI
D33 SCHOTTKY 40V 100MA SMINI
D34 DIODE, SKY, 40V, 2A, SMA
D35 DIODE, SKY, 40V, 2A, SMA
D36 DIODE, SKY, 300MA, 40V, DUAL, SERIES,
SOT-23
D37 TVS 5.5VWM 100VC SOT5
Reference
Designator
Q2 MOSFET N-CH 60V 115MA SOT-23
Q3 MOSFET N-CH 60V 115MA SOT-23
Q4 MOSFET N-CH 60V 115MA SOT-23
Q5 MOSFET N-CH 60V 115MA SOT-23
Q6 MOSFET N-CH 60V 115MA SOT-23
Q7 MOSFET N-CH 60V 115MA SOT-23
Q8 MOSFET N-CH 60V 115MA SOT-23
Q9 MOSFET N-CH 60V 115MA SOT-23
Q10 MOSFET N-CH 60V 115MA SOT-23
MAIN DSP PCB PART LIST
Diodes (continued)
Description
Transistors
Description
Vendor
TEXAS INST.
TEXAS INST.
TEXAS INST.
BOURNS
BOURNS
BOURNS
BOURNS
BOURNS
TOSHIBA
TOSHIBA
TOSHIBA
TOSHIBA
TOSHIBA
TOSHIBA
BOURNS
BOURNS
BOURNS
BOURNS
BOURNS
ST MICRO
TOSHIBA
TOSHIBA
TOSHIBA
TOSHIBA
TOSHIBA
DIODES INC
DIODES INC
ST MICRO
TEXAS INST.
Vendor
FAIRCHILD
FAIRCHILD
FAIRCHILD
FAIRCHILD
FAIRCHILD
FAIRCHILD
FAIRCHILD
FAIRCHILD
FAIRCHILD
34
Vendor Part Number
TPD4S012DRYR
TPD4S012DRYR
TPD2E007DCKR
SMAJ5.0A
SMAJ5.0A
SMAJ5.0A
SMAJ5.0A
SMAJ5.0A
1SS294,LF
1SS294,LF
1SS294,LF
1SS294,LF
1SS294,LF
1SS294,LF
SMAJ24A
SMAJ24A
SMAJ24A
SMAJ24A
SMAJ24A
DVIULC6-4SC6
1SS294,LF
1SS294,LF
1SS294,LF
1SS294,LF
1SS294,LF
B240A-13-F
B240A-13-F
BAT54SFILM
TPD2E001DRLR
Vendor Part Number
2N7002
2N7002
2N7002
2N7002
2N7002
2N7002
2N7002
2N7002
2N7002
Note
Note
