Reference
Designator
R50
0.0, 1/10W, JUMPER, 0402, SM
R51
33.0, 1/10W, 1%, 0402, SM
R52
33.0, 1/10W, 1%, 0402, SM
R53
33.0, 1/10W, 1%, 0402, SM
R54
10.0, 1/10W, 1%, 0402, SM
R55
33.0, 1/10W, 1%, 0402, SM
R56
33.0, 1/10W, 1%, 0402, SM
R57
33.0, 1/10W, 1%, 0402, SM
R59
100K, 1/10W, 1%, 0402, SM
R69
100K, 1/10W, 1%, 0402, SM
R71
100K, 1/10W, 1%, 0402, SM
R72
100K, 1/10W, 1%, 0402, SM
R73
100K, 1/10W, 1%, 0402, SM
R74
33.0, 1/10W, 1%, 0402, SM
R75
33.0, 1/10W, 1%, 0402, SM
R76
33.0, 1/10W, 1%, 0402, SM
R77
33.0, 1/10W, 1%, 0402, SM
R78
59.0, 1/10W, 1%, 0402, SM
R79
59.0, 1/10W, 1%, 0402, SM
R80
59.0, 1/10W, 1%, 0402, SM
R81
59.0, 1/10W, 1%, 0402, SM
R82
1.20K, 1/4W, 1%, 1206, SM
R83
33.0, 1/10W, 1%, 0402, SM
R84
33.0, 1/10W, 1%, 0402, SM
R85
33.0, 1/10W, 1%, 0402, SM
R86
10.0K, 1/10W, 1%, 0402, SM
R88
10.0K, 1/10W, 1%, 0402, SM
R89
10.0K, 1/10W, 1%, 0402, SM
R90
10.0K, 1/10W, 1%, 0402, SM
R91
10.0K, 1/10W, 1%, 0402, SM
R92
10.0K, 1/10W, 1%, 0402, SM
R93
10.0K, 1/10W, 1%, 0402, SM
R94
10.0K, 1/10W, 1%, 0402, SM
R95
10.0K, 1/10W, 1%, 0402, SM
R96
10.0K, 1/10W, 1%, 0402, SM
R98
10.0K, 1/10W, 1%, 0402, SM
R102
1.20K, 1/4W, 1%, 1206, SM
R103
33.0, 1/10W, 1%, 0402, SM
R104
10.0K, 1/10W, 1%, 0402, SM
R105
33.0, 1/10W, 1%, 0402, SM
R106
10.0K, 1/10W, 1%, 0402, SM
R107
33.0, 1/10W, 1%, 0402, SM
R109
33.0, 1/10W, 1%, 0402, SM
MAIN DSP PCB PART LIST
Resistors (continued)
Description
Vendor
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
PANASONIC
12
Vendor Part Number
ERJ-2GE0R00X
ERJ-2RKF33R0X
ERJ-2RKF33R0X
ERJ-2RKF33R0X
ERJ-2RKF10R0X
ERJ-2RKF33R0X
ERJ-2RKF33R0X
ERJ-2RKF33R0X
ERJ-2RKF1003X
ERJ-2RKF1003X
ERJ-2RKF1003X
ERJ-2RKF1003X
ERJ-2RKF1003X
ERJ-2RKF33R0X
ERJ-2RKF33R0X
ERJ-2RKF33R0X
ERJ-2RKF33R0X
ERJ-2RKF59R0X
ERJ-2RKF59R0X
ERJ-2RKF59R0X
ERJ-2RKF59R0X
ERJ-8ENF1201V
ERJ-2RKF33R0X
ERJ-2RKF33R0X
ERJ-2RKF33R0X
ERJ-2RKF1002X
ERJ-2RKF1002X
ERJ-2RKF1002X
ERJ-2RKF1002X
ERJ-2RKF1002X
ERJ-2RKF1002X
ERJ-2RKF1002X
ERJ-2RKF1002X
ERJ-2RKF1002X
ERJ-2RKF1002X
ERJ-2RKF1002X
ERJ-8ENF1201V
ERJ-2RKF33R0X
ERJ-2RKF1002X
ERJ-2RKF33R0X
ERJ-2RKF1002X
ERJ-2RKF33R0X
ERJ-2RKF33R0X
Note
