Bose ControlSpace EX-1280C Service Manual page 77

Reference
Designator
C800 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C801 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C802 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C803 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C804 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C805 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C806 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C807 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C850 E CAP, 330UF, 25V, 20%, 40C, T&R
C851 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C852 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C853 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C854 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C856 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C857 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C858 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C900 E CAP, 33UF, 25V, 20%, 55C, T&R
C901 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C902 Y5V, 0.1UF, 50V, 20%, 0603, T&R
C903 E CAP, 10UF, 16V, 20%, 55C, T&R
Reference
Designator
FB100 IND, 1K, 25%, 0603
FB101 IND, 1K, 25%, 0603
FB102 0 OHM, 1A, 0603
FB150 IND, 1K, 25%, 0603
FB151 IND, 1K, 25%, 0603
FB152 0 OHM, 1A, 0603
FB200 IND, 1K, 25%, 0603
FB201 IND, 1K, 25%, 0603
FB202 0 OHM, 1A, 0603
FB250 IND, 1K, 25%, 0603
FB251 IND, 1K, 25%, 0603
FB252 0 OHM, 1A, 0603
FB300 IND, 1K, 25%, 0603
FB301 IND, 1K, 25%, 0603
FB302 0 OHM, 1A, 0603
FB350 IND, 1K, 25%, 0603
FB351 IND, 1K, 25%, 0603
FB352 0 OHM, 1A, 0603
FB400 IND, 1K, 25%, 0603
OUTPUT PCB PART LIST
Capacitors (continued)
Description
Inductors
Description
77
Vendor Vendor Part Number
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
United EMVA250ADA331MHA0G
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
Panasonic EEE-FT1E330AR
Murata GRM188F11H104ZA01D
Murata GRM188F11H104ZA01D
United EMVY160ADA100MD55G
Vendor Vendor Part Number
Taiyo Yud BK1608HS102-T
Taiyo Yud BK1608HS102-T
KOA RK73Z1JTTD
Taiyo Yud BK1608HS102-T
Taiyo Yud BK1608HS102-T
KOA RK73Z1JTTD
Taiyo Yud BK1608HS102-T
Taiyo Yud BK1608HS102-T
KOA RK73Z1JTTD
Taiyo Yud BK1608HS102-T
Taiyo Yud BK1608HS102-T
KOA RK73Z1JTTD
Taiyo Yud BK1608HS102-T
Taiyo Yud BK1608HS102-T
KOA RK73Z1JTTD
Taiyo Yud BK1608HS102-T
Taiyo Yud BK1608HS102-T
KOA RK73Z1JTTD
Taiyo Yud BK1608HS102-T
Note
Note
