Orient the product with the ventilation slots towards the top to permit proper heat dissipation. When installed in an enclosure, select one that pro-
vides sufficient surface area to dissipate the heat generated by the product and by any other devices installed in the enclosure. A metal enclosure is
preferred. If necessary, provide active cooling for the enclosure.
£ The device's datasheet specifies the power consumption (amount of heat generated), the operating temperature range, and other environmental
conditions the device is designed to operate under.
£
Do not drop the product or subject it to physical shock.
£
If the product is used and/or installed in a manner not specified by Distech Controls, the functionality and the protection provided by the product may
be impaired.
£
SELV (Separated Extra Low Voltage) inputs/outputs must be connected to class 3 devices or to SELV sections of class 2 devices.
£
If the device is to be mounted on a metallic support, this same metallic support is to be connected to a protective earth.
£
-WD modules can be wall-mounted or DIN-rail-mounted. Conductors must be made inaccessible and wiring must comply with local wiring regula-
tions and methods appropriate for fixed equipment installation in a building (the use of trunking for example).
£
-ST and -STP modules without strain relief and terminal block covers must be wall-mounted or DIN-rail-mounted inside a supplementary enclosure
(rated as IP20 or better) that can only be accessed by qualified personnel.
£
-ST and -STP modules with strain relief and terminal block covers can only be wall-mounted on a flat surface that is sufficiently large to provide
space around the equipment. In this installation scenario, conductors must be made inaccessible and wiring must comply with local wiring regula-
tions and methods appropriate for fixed equipment installation in a building (the use of trunking for example).
Any type of modification to any Distech Controls product will void the product's warranty
Operating, handling, or servicing this product should be ensured by a qualified operator. The ECx-Light/Blind
series includes two sources of power: the main power supply and subnet. Turn off both power sources before
any kind of servicing.
Take reasonable precautions to prevent electrostatic discharges to the product when installing, servicing, or
operating it. Discharge any accumulated static electricity by touching a grounded object with your hand before
handling the product.
Device Markings
Certain markings (symbols) can be found on the side of the product and are defined as follows:
Symbol
CE marking: the device conforms to the requirements of applicable EC directives.
UKCA marking: the device conforms to the requirements of applicable Great Britain regulations.
UL marking: conforms to the requirements of the UL certification.
Products must be disposed of at the end of their useful life according to local regulations.
Read the Hardware Installation Guide for more information.
For indoor use.
Protective earth
FCC marking: This device complies with FCC rules part 15, subpart B, class B.
Warning Symbol: Significant information required. Refer to the Hardware Installation Guide.
HIGH VOLTAGE Symbol: Direct contact will cause electrical shock or burn.
Alternating Current
Direct Current
Line
Neutral
2 / 21
