- Page 1 Doc. no.IZ*-OMP0013-A PRODUCT NAME Ionizer MODEL / Series / Product Number IZF10 series １...
-
Page 2: Table Of Contents
Doc. no.IZ*-OMP0013-A Contents Safety Instructions 1. How to Order 1-1. Ionizer 1-2. Accessory 1-3. Maintenance parts 1-4.Option 2. Procedure 3. Installation and wiring 3-1. Installation 3-1-1. Precautions for installation 3-1-2. Mounting 3-2. Wiring 3-2-1. Wiring diagram and Wiring table 3-2-2. Connection cable and connector 3-2-3. -
Page 3: Safety Instructions
Doc. no.IZ*-OMP0013-A IONIZER Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 Doc. no.IZ*-OMP0013-A IONIZER Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
- Page 5 Doc. no.IZ*-OMP0013-A Selection 選定 Warning 1. This product is intended for use in general factory automation systems. 2. Use within specified voltage and temperature limits. Voltage out of specification may cause malfunction, damage, electric shock and/or fire. 3. This product does not have an explosion-proof construction. Do not use this product in areas where dust explosion might be triggered or where flammable or explosive gas is present.
- Page 6 Doc. no.IZ*-OMP0013-A Wiring and piping Warning 1. Check the capacity of the power supply is enough and the voltage is within the specified range before wiring. 2. Be sure to use the UL listed power supply specified by NEC (National Electric Code) to be a class 2 output or the limited power source evaluated in accordance with UL 60950.
- Page 7 Doc. no.IZ*-OMP0013-A Maintenance and Check Warning 1) Perform maintenance regularly and clean the electrodes. It is recommended to perform maintenance every week or when the contamination detection LED turns ON. Check regularly that the product is not operating with undetected failures. The maintenance must be carried out by an operator who has sufficient knowledge and experience.
-
Page 8: How To Order
Doc. no.IZ*-OMP0013-A 1. How to Order 1-1.Ionizer IZF10 Fan type Air flow 0.66m /min Ｌ 0.46m /min Out put NPN output PNP output 1-2. Accessory Power supply cable Power supply cable, AC adapter with Power supply cable (3m) with Power supply cable (10m) with AC adapter, with AC cord with AC adapter, without AC cord Note) AC cord is Japanese type (rated voltage: 125V) -
Page 9: Maintenance Parts
Doc. no.IZ*-OMP0013-A Bracket Note) Four retaining bolts are included. 1-3. Maintenance parts Cartridge case 1-4. Option Electrode needle cleaning kit IZS30- M2 IZS30-A0201 IZS30-A0202 （Felt, rubber grindstone: (Felt for replacement 10pcs.) (Rubber grindstone for one of each） replacement one pc.) Screwdriver for ion balance adjustment trimmer IZS30- M1 ９... -
Page 10: Procedure
Doc. no.IZ*-OMP0013-A 2. Procedure Start Refer to [3-1. Installation] Installation Wiring Refer to [3-2. Wiring] Power supply Refer to [4-2. Fine adjustment of ion balance] Fine adjustment of ion balance 3. Installation and wiring We recommend investigating environments where static electricity is generated and processes and parts where static electricity disturbance occur in advance, and thoroughly confirming the conditions in order to remove static electricity effectively before installation. -
Page 11: Mounting
Doc. no.IZ*-OMP0013-A Do not touch the electrodes with a finger or metal tool directly. It may cause injury or malfunction. If the electrodes are touched with a finger, injury or damage may result or if the electrodes are touched with metal tools damage may result. -
Page 12: Wiring
Doc. no.IZ*-OMP0013-A 2) Installation without bracket If a bracket is not used, install the product using the M4 screw holes on the sides of the body. (Screws are not supplied) Refer to section 6 Dimensions for details. M4 screw recommended tightening torque: 1.3 to 1.5Nm. 3-2. - Page 13 Doc. no.IZ*-OMP0013-A ＰＮＰ output Power supply Ionizer Pin no. Pin no. Description Contents DC+24V Ionizer driving power supply cable Connect to ground with a lead resistance of less than 100Ω. If these connections are not made correctly, the Ionizer may become F.G.
-
Page 14: Connection Cable And Connector
Doc. no.IZ*-OMP0013-A 3-2-2.Connection cable and connector 1) The connectors are designed to accept wiring between 26 AWG and 24 AWG. Accept wiring Wire range Outside Diameter Product number Φ0.8-Φ1.0 26-24 0.14-0.2 ZS-28-C 2) Insert each lead wire into the connector. 3) After verifying that the wires are fully inserted temporarily hold A down by hand. -
Page 15: Timing Chart
Doc. no.IZ*-OMP0013-A 3-3. Timing chart Exceeding the rated Normal condition Abnormal high voltage Maintenance current Power Display Condition Warning Error Error ― Input Power switch Error signal ― （The signal is turned off Output when error occurs） Power supply (Green) POWER Exceeding the rated current for output circuit... -
Page 16: Fine Adjustment Of Ion Balance
Doc. no.IZ*-OMP0013-A 4-2. Fine adjustment of ion balance The ion balance of the ionizer is adjusted before shipment. However, readjustment might be required depending on the installed environment, so fine adjustment can be performed. Use a trimmer for balance fine adjustment to perform fine adjustment of the ion balance. When performing fine adjustment of the ion balance, use a measuring instrument such as a charged plate monitor. -
Page 17: Replacement Of The Cartridge Case
Doc. no.IZ*-OMP0013-A The cleaning kit has felt and rubber grindstones on the ends. Choose the felt or rubber grindstone depending on the level of contamination to effectively clean the electrodes. Felt: Use for normal cleaning Rubber: Use if contamination is hard and stuck to the electrodes and it is not possible to remove it with felt. Felt Rubber grindstone 4) Put the cartridge case back in its original position by reversing the removal procedure. -
Page 18: Electricity Removal Characteristics
Doc. no.IZ*-OMP0013-A 3) Maintenance If the electrodes become contaminated, worn out or damaged, the LED will turn ON. If the electrodes are contaminated, they can be cleaned, but if they are worn out or damaged, the cartridge case will have to be replaced. The ionizer will continue to operate after the alarm. -
Page 19: Dimensions
Doc. no.IZ*-OMP0013-A IZF10-L 8sec 4sec 6sec 2sec -300 1200 6. Dimensions １９... - Page 20 Doc. no.IZ*-OMP0013-A Power supply cable Part No. Pin no. Cable color Description IZF10-CP 3000 Brown DC+24V IZF10-CPZ 9850 +100 Blue Green F.G. Purple Error signal AC adapter IZF10-CG1 (with AC code) IZF10-CG2 (without AC code) Part No. AC cord IZF10-CG1 with AC cord IZF10-CG2 without AC cord ２０...
-
Page 21: Specifications
Doc. no.IZ*-OMP0013-A 7. Specifications Ionizer model IZF10-□□ IZF10-L-□□ IZF10-P-□□ IZF10-LP-□□ Air flow 0.66m /min 0.46m /min 0.66m /min 0.46m /min Ion generation Corona discharge type method Voltage applying method Discharge output +/-5ｋV Note1) Ion balance Note2) +/-13V or less Power supply DC24V+/-10 (%) voltage Power... - Page 22 Doc. no.IZ*-OMP0013-A Revision history (March.27.2024) Revision A The Safety Instructions. (p3, p4) The words deleted. (～please contact SMC before use.) (p5) The back cover. (p22) Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
