Doc.no.IZ*-OMT0002-A
PRODUCT NAME
Fan Type Ionizer
MODEL / Series / Product Number
IZF10R Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IZF10R Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SMC Networks IZF10R Series

  • Page 1 Doc.no.IZ*-OMT0002-A PRODUCT NAME Fan Type Ionizer MODEL / Series / Product Number IZF10R Series...
  • Page 2: Table Of Contents

    Doc. no. IZ*-OMT0002-A Contents Safety Instructions ........................2 1. How to Order .......................... 7 1-1. Product ..............................7 1-2. Accessories.............................. 7 1-3. Maintenance parts ........................... 8 1-4. Option ............................... 8 2. Procedures for Operation ...................... 8 3. Installation and wiring ......................9 3-1.
  • Page 3: Safety Instructions

    Doc. no. IZ*-OMT0002-A Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
  • Page 4 Doc. no. IZ*-OMT0002-A Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
  • Page 5 Doc. no. IZ*-OMT0002-A Selection Warning 1) This product is intended for use in general factory automation equipment. 2) Use within the specified voltage and temperature range. Operation with a voltage other than that specified can cause malfunction, damage to the product, electric shock or fire.
  • Page 6 Doc. no. IZ*-OMT0002-A 2) Make sure to confirm the effect of static neutralization after installation. The effects vary depending on the ambient conditions, operating conditions, etc. After installation, verify the effects of static neutralization. 3) Do not apply an excessive force to the finger guard. If an excessive external force is applied to the finger guard on the air intake side, it may be damaged.
  • Page 7 Doc. no. IZ*-OMT0002-A Maintenance Warning 1) Perform maintenance regularly and clean the emitters. High voltage caution It is recommended to perform maintenance every week or when the maintenance warning function turns ON. This product contains a high voltage Periodically inspect the electrostatic sensor to generation circuit.
  • Page 8: How To Order

    Doc. no. IZ*-OMT0002-A 1. How to Order 1-1. Product IZF10R Fan type Bracket None With Bracket Max. air flow: 0.80m Power supply cable, AC adapter Output specification With power supply cable (3 m) NPN output With power supply cable (10 m) PNP output With AC adapter (with AC cord) With AC adapter (without AC cord)
  • Page 9: Maintenance Parts

    Doc. no. IZ*-OMT0002-A 1-3. Maintenance parts Cartridge case IZF10R-A1 1-4. Option Cleaning kit IZS30- M2 IZS30-A0201 IZS30-A0202 (1 replacement rubber (With 1 felt pad, 1 rubber (10 replacement felt pads) grindstone) grindstone, and 2 replacement felt pads) Adjustment screwdriver IZS30- M1 2.
  • Page 10: Installation And Wiring

    Doc. no. IZ*-OMT0002-A 3. Installation and wiring The performance of the product varies depending on the surrounding installation and operating conditions. It is recommended to investigate in advance any environment where static electricity is generated, as well as processes and parts where static electricity disturbances occur. Verify that the required conditions have been met in order to effectively remove static electricity before installation.
  • Page 11: Product Body Installation

    Doc. no. IZ*-OMT0002-A 3-1-2. Product Body Installation 1) Installation with bracket A protective seal is affixed to the bracket, so remove it before use. When installing this product with a bracket, secure it with M5 screws using the mounting holes on the bottom of the bracket.
  • Page 12: Wiring

    Doc. no. IZ*-OMT0002-A 3-2. Wiring Wire cables according to the circuitry and wiring chart. 3-2-1. Connection Circuit Make sure to ground the F.G. cable (green) with a resistance of 100 ohms or less. F.G. cable is the standard electric potential for static electricity neutralization. If the F.G. cable is not grounded properly, an optimal offset voltage (ion balance) cannot be obtained, and it may damage this product and connected power supply.
  • Page 13 Doc. no. IZ*-OMT0002-A PNP output Shield IZF10R Green F.G. Ground the F.G. cable with a resistance of 100 ohms or less +24V Brown +24VDC +24V Power Blue 0V supply 24VDC F.G. Ground the F.G. cable with a OUTPUT resistance of 100 ohms or less +24V INPUT Yellow...
  • Page 14: Wiring Of The Power Supply Cable

    Doc. no. IZ*-OMT0002-A 3-2-2. Wiring of the power supply cable The cable bending radius should be at least the minimum bending radius so that stress is not applied to the mounting part of the power supply connector. Minimum bending radius: 10 mm Note: The ambient temperature should be 20 C for fixed wiring.
  • Page 15: Timing Chart

    Doc. no. IZ*-OMT0002-A 3-3. Timing chart Operation Incorrect high voltage Excess current on output circuit Maintenance warning Power Display Status Warning Error Error Note2) Note2) Power supply switch Maintenance Maintenance Error signal (ON during Note3) normal operation) Maintenance signal (OFF Note3) during normal operation)...
  • Page 16: Adjustment Of Offset Voltage (Ion Balance)

    Doc. no. IZ*-OMT0002-A 4-2. Adjustment of offset voltage (ion balance) Although the offset voltage (ion balance) of this product has been factory adjusted, readjustment may be required depending on the installation environment. The offset voltage can be adjusted by a balance adjustment trimmer.
  • Page 17 Doc. no. IZ*-OMT0002-A - Replacement and cleaning of cartridge case - 1) Be sure to disconnect the power supply before installation and cleaning. The fan motor rotation will not stop immediately due to inertial force even when the power is OFF. Confirm that it stops before moving to the next step.
  • Page 18: Replacement Of Cartridge Case

    Doc. no. IZ*-OMT0002-A 4-5. Replacement of Cartridge Case If the emitters are worn out or damaged, replace the cartridge case. Before replacing the cartridge case, make sure that the power supply is OFF and confirm that the fan motor has stopped. Never perform cleaning or replace the emitters when the fan motor is rotating. The fan rotation may cause injury.
  • Page 19: Performance

    Doc. no. IZ*-OMT0002-A 5. Performance Performance data given in this chapter is based on an electrified plate (dimensions: 150 x 150 mm, electrostatic capacity: 20 pF) defined by ANSI standard (ANSI/ESD STM3.1-2006). Use this data as a guideline for selection, as the performance data may vary depending on the material and size of the work piece.
  • Page 20: Dimensions

    Doc. no. IZ*-OMT0002-A 6. Dimensions Bracket mounting Holding bolt Bracket Air flow adjustment switch LED display Power supply switch Balance adjustment trimmer Through hole Side view of the body Depth 1 Depth 6 (Mounting female thread) Variable angle 1.9 (Power supply switch) - 19 -...
  • Page 21 Doc. no. IZ*-OMT0002-A Power supply cable Semi-stripped terminal Shield Wiring Conductor Part no. Pin No. Cable color Signal name size(AWG) IZF10R-CP 3000 Brown +24 VDC +100 IZF10R-CPZ 9850 Blue Green F.G. Yellow Maintenance signal Purple Error signal AC adapter IZF10R-CG1 (With AC cord) F.G.
  • Page 22: Specifications

    Doc. no. IZ*-OMT0002-A 7. Specifications Model IZF10R (NPN output) IZF10R (PNP output) Maximum air flow 0.80 m /min Ion generation method Corona discharge type Method of applying DC type voltage Applied voltage +/-5 kV Offset voltage +/-13 V Note ) (ion balance) Power supply voltage 24 VDC +/- 10%...
  • Page 23 Doc. no. IZ*-OMT0002-A Revision history Revision A (March.27.2024) The Safety Instructions. (p2, p3) The words deleted. (Consult SMC before using this product for other intentions. (See Warning No. 4 on page 3) (p4) The words changed. (Danger→caution) (p6,p9) The back cover. (p22) Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note:...
