3 types of the sensors

are available.
• Autobalance sensor [High-precision type]
Adjusts offset voltage near the workpiece
to reduce any disturbance interference!
• Autobalance sensor [Body-mounting type]
Controlled offset voltage by sensor Controlled offset voltage by sensor
Ionizer
IZS31
Series
• Rapid neutralization of static electricity
by a feedback sensor:
Conditions / Discharge time from 1000 V to 100 V
Installation distance: 200 mm (Tungsten emitter with air purge)
Continuously emits ions in accordance with the
polarity applied onto a workpiece.
20
15
10
5
<Conditions> Static neutralization features are based on the data using the
charged plate (size: 150 mm x 150 mm, capacitance: 20 pF) as defined in the
U.S. ANSI standards (ANSI/ESD, STM3. 1-2015). Use this as a guideline
purpose only for model selection because the value varies depending on the
material and/or size of a subject.
According to the establishment of the JIS Glossary of Terms, the applicable terms
were changed to JIS terms. Refer to the JIS C 61340-4-7 for more details.
0.3
Discharged object: Charged plate
(150 mm x 150 mm, capacitance 20 pF)
Supply pressure: 0.1 MPa (7 L/min (ANR) per nozzle)
Installation height of sensor: 10 mm
Without sensor
With sensor
0 500 1000
Distance (mm)
RoHS
seconds
1500 2000
