1 — Power socket
2 — Ethernet socket
3, 4 — Slots for installing micro-SIM cards
3. Press and hold the power button for 3 seconds until the Ajax logo lights up. It takes about 2
minutes for the hub to upgrade to the latest Drmware and connect to the Internet. The green
or white logo color indicates that the hub is running and connected to Ajax Cloud.
4. To connect to the cellular network, you need a micro SIM card with a disabled PIN code
request (you can disable it using a mobile phone) and a succient amount on your account
to pay for the services at your operator's rates. If the hub does not connect to the cellular
network, use Ethernet to conDgure the network parameters: roaming, APN access point,
username, and password. Contact your telecom operator for support to Dnd out these
options.
Adding a hub to the Ajax app
1. Turn on the hub and wait until the logo lights up green or white.
2. Open the Ajax app. Give access to the requested system functions to fully use the capabilities of the Ajax app and not
to miss alerts about alarms or events.
How to set up noti=cations on iOS
How to set up noti=cations on Android
3. Open the Add hub menu Select the way of registering: manually or step-by-step guidance. If you are setting the system
up for the Drst time, use step-by-step guidance.
4. Specify the name of the hub and scan the QR code located under the SmartBracket mounting panel or enter it
manually.
5. Wait until the hub is added. The linked hub will be displayed in the Devices tab
https://support.ajax.systems/en/manuals/hub-2-plus/?_ga=2.241650955.824691895.1674290377-1071851791.1672842436
If the Ethernet connection is not established automatically, disable proxy and MAC address Dltration and
activate DHCP in the router settings. The hub will automatically receive an IP address. After that, you will
be able to set up a static IP address of the hub in the Ajax app.
