Description; Features; Specifications - J-Tech Digital JTD-3021 User Manual

1. Description

JTECH-14EXP is a 164ft. (50m) extender with 1 HDMI input and 4 UTP output. It supports
1080P 60Hz. The 1x4 extender has the ability to equalize and amplify to ensure that the HDMI
signal is transmitter without loss of quality. This splitter can be used for digital entertainment
centers, retail and display websites, set-top boxes, security rooms, data control centers,
conference rooms, schools, and enterprise training environments.

2. Features

1 x HDMI Input | 1 x HDMI Loop-out & 4 x UTP Outputs
•
1080P 60Hz up to 164ft. over single CAT5e/6
•
HDCP 1.4 compliant
•
Supports USB updating
•
Audio formats such as LPCM 2.0, Dolby Digital, DTS
•
Supports PoC (Receivers are powered by the transmitter)
•

3. Specifications

Ports
Audio
Resolutions
1 x HDMI Type 19-pin
4 x RJ45 ports
LPCM 2.0 / LPCM 7.1 / DTS 7.9 / AC-3-5.1
1080P 60 / 50 / 30 / 25 / 24 Hz
1080i 60Hz
720P 60 / 50 / 30 Hz
576P 50Hz
576i 50Hz
3
