10

Specifications

Electrical Connections
Power Requirements
Approvals
Physical Dimensions
Weight
Operating Temperature
Humidity
NOTE: Specifications subject to change without notice.

10.1 Warnings

FCC Class B
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

10.2 Compliance with EN IEC 62368-1

For EN IEC compliance, the following instructions must be met when operating the ProtoNode.
• The units shall be powered by listed LPS or Class 2 power supply suited to the expected operating temperature
range.
• The interconnecting power connector and power cable shall:
◦ Comply with local electrical code
◦ Be suited to the expected operating temperature range
◦ Meet the current and voltage rating for the FieldServer
• Furthermore, the interconnecting power cable shall:
◦ Be of length not exceeding 3.05m (118.3")
◦ Be constructed of materials rated VW-1, FT-1 or better
• If the unit is to be installed in an operating environment with a temperature above 65 °C, it should be installed in a
Restricted Access Area requiring a key or a special tool to gain access.
• This device must not be connected to a LAN segment with outdoor wiring.
US
One 3-pin Phoenix connector with: RS-485/RS-232 (Tx+ / Rx- / gnd)
One 3-pin Phoenix connector with: RS-485 (+ / - / gnd)
One 3-pin Phoenix connector with: Power port (+ / - / Frame-gnd)
One Ethernet 10/100 BaseT port
Input Voltage:12-24VDC or 24VAC
Max Power: 3 Watts
FCC Part 15 B, CAN/CSA C22.2 No. 60950-1, EN IEC 62368-1, DNP 3.0 and Modbus
conformance tested, BTL marked, WEEE compliant, RoHS compliant, REACH compliant,
UKCA and CE compliant, ODVA conformant, CAN ICES-003(B) / NMB-003(B)
4 x 1.1 x 2.7 in (10.16 x 2.8 x 6.8 cm)
0.4 lbs (0.2 Kg)
-20°C to 70°C (-4°F to158°F)
10-95% RH non-condensing
Lochinvar ProtoNode FPC-N54 Guide
FPC-N54
Current draw: 24VAC 0.125A
12-24VDC 0.25A @12VDC
10 Specifications
