10.7 Specifications

Electrical Connections
Approvals
Power Requirements
Physical Dimensions
Weight
Operating Temperature
Surge Suppression
Humidity
Warning: This equipment is compliant with Class A of CISPR 32. In a residential environment, this equipment
may cause radio interference.
FPC-C34
FPC-C35
FPC-C38
ProtoCarrier FPC-C39
FPC-C40
FPC-C41
FPC-C42
1. Tx/Rx/GND
38
ProtoCarrier FPC-C34/C38
One 6-pin Phoenix connector with:
RS-485 port (+ / - / gnd)
Power port (+ / - / Frame-gnd)
One 3-pin Phoenix connector with:
RS-485 port (+ / - / gnd)
One Ethernet 10/100 BaseT port
CE and FCC Part 15 certified, UL 916 approved, WEEE compliant, REACH compliant,
EN 50491-3 and CSA C22.2 standards, DNP 3.0 and Modbus conformance tested,
RoHS 3 compliant, CSA 205 approved, UKCA compliant
9-30VDC or 12-24VAC
11.5 cm L x 8.3 cm W x 4.1 cm H (4.5 x 3.2 x 1.6 in.)
0.2 kg (0.4 lbs)
-20 to 70°C (-4 to 158°F)
EN61000-4-2 ESD EN61000-4-3 EMC EN61000-4-4 EFT
5-90% RH (non-condensing)
NOTE: Specifications subject to change without notice.
RS-232 1 RS-485 2
1
1
2. +/-/Frame Ground
ProtoCarrier Start-up Guide
ProtoCarrier FPC-C35/C39
One 6-pin Phoenix connector with:
RS-485 port (+ / - / gnd)
Power port (+ / - / Frame-gnd)
One Ethernet 10/100 BaseT port
One FTT-10 LonWorks port
LonMark Certified
Interface Connections
Ethernet 3
2 1
1 1
1 1
1
1 1
1
1 1
3. 10/100 BaseT
LonWorks 4 KNX 2
1
1
1
1 1
4. FTT 10
M-Bus 2
1
